Specifications
waterproof LED Driver1. in factory price
2. 2-7 working days delivery
3.CE&ROHS approval
4.3 yeas warranty
100w waterproof LED Driver , LED Driver, LED Adapter for led strips and led module
1. Features
1.Input voltage: AC85-265V
2. Power: 100W
3. USA,Eu,Au plug optional
4.Output volt:DC12V/24V
5. IP67 with Metal housing
6.High Efficiency and good price
7.Built-in EMI filter
8.100% full load burn-in test
9.Low output ripple and noise
10.Protection:Over load/Over voltage/Short circuit
Specifications:
2. Environmental Conditions
1 Operating Temperature: -10/+50 degree, 20%/95%RH(without condensation)
2 Storage Temperature: -20/+85 degree, 20%/95%RH(without condensation)
3 Relative Humidity: 0.02/0.05% degree
4 Heat-dissipating Method: Natural Cooling / Fan Cooling / Blower Cooling
3. Input Features
1, Input Voltage Range: 110/240VAC±15%
2, Input Frequency Range:50/60Hz(except Dc input)
3, Input Under-voltage Protection:115/150%interim mode
4, Input Under-voltage Recovery: Automatic recovery
5, Input Over-voltage Protection:115/150% interim mode
6, Input Over-voltage Recovery: Automatic recovery
7, Impact Current ≤1% (the highest input voltage full load)
8, Overall Efficiency ≤0.5% (rated input full load)
4. Output Features
1 Output Voltage Range:12V/ 24V±2%(Triple Outputs)
2 Output Current Range: 12.5A/6.25A±0.5%(Triple Outputs)
3 Ripple & Noise(mVp-p)≤100 mVp-p
4 Rise Time≤50 ms
5 Output Delay≤S
6 Voltage Adjustment Rate≤0.5%
7 Load Adjustment Rate≤1%
5. Protective Feature
1 Output Over Current Protection: Current drooping type
2 Output Short Circuit Protection: IGBT
3 Output Over-voltage Protection: Soft start protection
6. Reliability Requirements
1 MTBF:50,000 HOURS
2 Annual Repair Rate less than 0.3%
Applications
- Household lighting;
- Hotel, Restaurant lighting;
- Office , Artwork, Display items lighting;
- Commercial lighting, such as Flood light, Down light, Flexible strip light, Wall washer, etc;
- Other public facility lighting.
