Relay 4 Pin 10A 16A 125VAC

Relay 4 Pin 10A 16A 125VAC thumbnail-1
Relay 4 Pin 10A 16A 125VAC photo-1
US$ 0.5 - 0.75 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
YONGNENG
Model Number:
YX206F
Contact Supplier Request Quote Chat Now
Dongguan Yongneng Electronics Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen Dongguan Hongkong
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name YONGNENG
Model Number YX206F
Theory Electromagnetic Relay
Usage General Purpose
Size Miniature
Protect Feature Sealed
Contact Load High Power

PCB Relay 4 Pin SPST 10A 16A 125VAC 23X16.1X10.2 mm



Description:



Smaller size :23 X16.1 X10.2 mm



Rohs and Reach Compliance



High switching capability:16A



High sensitivity :200 mW coil power



Plastic Sealed Type Available



Applications:



Home Appliance



Office machine



Electric heater



Vending machine



Air Conditioner



Sepecifications :



PCB Power Relay



Home Appliance Relay



Electromagnetic Relay



General Purpose Power Relay



Model

YX206F

Contact Form

1a

Contact Material

Silver Alloy

Rated Load

10A/16A 277VAC 30VDC

Max.Switching Current

16 A

Max. switching voltage

277VAC/30VDC

Max. switching capacity

2770VA




CHARACTERISTICS DATA




Insulation Resistance

1000MΩMin at 500VDC

Dielectric Strength Between Open Contacts

1000VAC(50/60Hz for one minute)

Between Contacts and coil

2500VAC(50/60Hz for one minute)

Operate Time

15 ms

Release Time

8 ms

Temperature Range

-40℃to+85℃

Shock Resistance

Operating Extremes: 10G

Damage Limits: 100G

Vibration Resistance

10-55Hz, 1.5mm

Weigh

Approx 8.8 g

Safety Standard

Rosh and Reach Compliance



Relay 4 Pin 10A 16A 125VAC

Dongguan Yongneng Electronics is a medium-sized factory who specializes in RELAY field for 10



YEARS . We produce Signal Relay , PCB power relay and automotive relay and so on .



As the reliable supplier of Philips , Supor ,Joyoung and East UPS, each year Yongneng supply Power

Relay , Signal Relay, Automotive Relay for them with large quantity .
