300w par56 led replacement for swimming pool

Specifications

300w par56 led replacement
1). high power LED, SMD5050 LED
2). aa177*108mm.
3). RGB color, RGB control or DMX
4). CE&ROHS

Advantages of PAR56:

1.New private mould & patent
2.good waterproof & dustproof Par56 Led swimming pool light ip68
3.good anti-corrosion performance and could be used in sea or salted-water condition
4.wide options:15w,18w, 20w, 21w, 24w, 25w, 30w,35w, SMD5050,DIP F5,18*1W,18*1W(3 in 1), 12*3W, 18*3W
Chip on Board integreted for 21W, 25W, 30W,35W for customers' options.
5.High brightness & Lumen: 25w 2000Lm and 30w 2600Lm,35w 3200Lm
6.Remote synchronization function

Features:

1. Sole & Patented design
2. Size: 178(diameter) * 108(height) mm
3. 6063 die-casting aluminium cup which ensure lamp cup/body unbreakable & good heat difussion, and make sure of less lumens decline.
4. Transparent PC cover, anti-corrosion, shock-proof, unbreakable, safe transportation
5. IP68 with lamp housing
6. Constant driver to make sure LED light working stably, avoid any flashing and noisy
7. Voltage: DC12V,       Frequency: 50/60HZ
8. High quality and brightness LED source
9. Projection distance: 10-20 meter
10. Color: RGB, 15 kinds of color changing method.
11. 4 kinds of RGB control mode: built-in(automatical control), wire/line control, remote and switch control
12. Beam angle: DIP-25°or 120°, SMD5050-120°, high power-25°or 30°or 45°or 60°
13. Life span 50000 hours
14. Overcurrent protection

Applications: Swimming pool, park, water-fall, fountain spring, gardon.

Main parameters:



Specification	Parameter
Item No.	BG-PAR56-03	BG-PAR56-04	BG-PAR56-05	BG-PAR56-06
LED Qty.	105pcs  SMD5050	252 pcs  DIP F5	315 pcs  DIP F5	18*1W/3W
Working Voltage	AC/DC 12V	AC/DC 12V	AC/DC 12V	AC/DC 12V
Voltage Frequency	50-60Hz	50-60Hz	50-60Hz	50-60Hz
Power	19±1w(white)    16±1w (rgb)	15±1w(white)    14±1w (rgb)	19±1w(white)    18±1w (rgb)	20±1w(white)    19±1w (rgb)
Luminous flux	ww/cw: 1050lm pw:1200lm     RGB:200-800lm	ww/cw:900lm   pw:1000lm    RGB:200-800lm	ww/cw: 1100lm pw:1250lm     RGB:200-800lm	ww/cw:1100lm   pw:1300lm    RGB:200-800lm
Working temperature	-20-60°C	-20-60°C	-20-60°C	-20-60°C
Color temperature	p.w.-6000~7000k w.w.:3000-3500k c.w.-8000~12000	p.w.-6000~7000k w.w.:3000-3500k c.w.-8000~12000	p.w.-6000~7000k w.w.:3000-3500k c.w.-8000~1200k	p.w.-6000~7000k w.w.:3000-3500k c.w.-8000~1200k
Color temperature   (RGB)	R/G/B:621 -625/ 518 -520/ 464 -467 K/nm	R/G/B:621 -625/ 518 -520/ 464 -467 K/nm	R/G/B:621 -625/ 518 -520/ 464 -467 K/nm	R/G/B:621 -625/ 518 -520/ 464 -467 K/nm
Dimension	177×108 mm	177×108 mm	177×108 mm	177×108 mm
Storage Temperature	-10-60°C	-10-60°C	-10-60°C	-10-60°C
Base	G53/wire	G53/wire	G53/wire	G53/wir
IP rate(w/housing)	IP68	IP68	IP68	IP68
Control mode	RGB/DMX	RGB/DMX	RGB/DMX	RGB/DMX
