Electric heating element 2kw/3kw/5kw water heating tube
Electric heating element 2kw/3kw/5kw water heating tube Description:
Industrial Finned Tubular Heater with Mounting Fittings is a tube-shaped, heavy-duty, industrial joule heating element (electrical resistance) used in the process heating industry, usually custom manufactured to a specific watt density, based on its intended application. Highly compacted they reach a surface watt density of up to 30 w/cm².
Industrial Finned Tubular Heater with Mounting Fittings may be used to heat any kind of substance or material, such as oil, air, or sugar. However, a common application is plastic pellets, which are melted in order to form molded plastic parts. An example of such a process is the "hot runner" process. Industrial Finned Tubular Heater with Mounting Fittings resemble tubular heaters structurally but tend to have higher watt densities.
- Tube diameter: Φ3mm-Φ30mm
-Tube Material:SS304;SS316,SS321,NICOLOY800 etc
-Insulation Material:High-purity Mgo
- Reisistance wire element:Ni-Cr or FeCr
- Lead Connection Option: Crimped or Swaged leads
- Lead and type of connection leads, 10" Fiberglass Standard(Wire options,silicone high temperature frberglass).
heating tubes are customized according to your specifications.
MODEL |
DIMENSION(MM) |
VOLTAGE(V) |
POWER(W) |
LK-GZ-Φ12x1000 |
Φ12x1000 |
220 |
2000 |
LK-GZ-Φ14X1500 |
Φ14X1500 |
220 |
3000 |
LK-GZ-Φ16X2000 |
Φ16X2000 |
220 |
4000 |
LK-GZ-Φ20X1600 |
Φ20X1600 |
220 |
4500 |
Note: Other models are available according to your specifications. Please refer to the order guide. | |||
Heat intensity |
Not exceeding 30Wcm2 (advisable) |
Power |
Depends on the dimension |
Escape of current (when cold) |
<=0.1mA a 242 v. |
Insulation (when cold) |
5 Min Ohmios 500 Watts minimum |
Dielectric strength |
1500v. 1/seg |
Working temperature |
750ºG max. |
Tolerance of length |
+/-1.5% |
Tolerance of diameter |
-0.01 a -0.06 m/m |
Tolerance of cut of connexion |
+/-15 mlm |
Power tolerance (w) |
5 % - 10 % |
Cold areas |
Depends on length and diameter 5-25mm |
Electric heating element 2kw/3kw/5kw water heating tube Applications:
Plastic Processing machinery.
Water and Oil Heating Appliances.
Packaging machineries
Vending Machines.
Dies and Tools.
Heating Chemical Solutions.
Ovens & Dryers
Kitchen equipments
Medical equipments
Electric heating element 2kw/3kw/5kw water heating tube Images:
Enamel Heating Tube Production:
Company Information
Packaging: Tubualr heater in plywood case outside if needed.
Shipment: 1.small quantity by DHL, FEDEX
2.Bulk goods by Sea Freight
3. Arranged to your order
Order Guide:
Please specify the following when ordering:
1. Diameter (mm) of tubular heaters
2. Total length of heaters when extended (mm)
3. Tube Material (sus304, sus316, sus316L)
4. Type of leads and length
5. Voltage and power density
6. Content of the stamping if needed
7. Order quantity
8. Delivery date
As it is difficult to see the internal construction of tubular heaters, it’s better to provide us with the drawings/pictures
