Product Details
Condition: | New | Type: | Other, Injection Moulding machine mica heater | Power Source: | Electric |
Place of Origin: | Jiangsu, China | Brand Name: | DragonPower | Model Number: | LK-YM |
Dimension(L*W*H): | 55*80 | Weight: | 0.1KG | Voltage: | 220v,380v |
Power(W): | 500w-3000w | Certification: | CE,ROHS | Warranty: | 2 yers |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Description: Injection Moulding machine mica heater:
Technology: Injection Moulding machine mica heater is used Cr20Ni80 mica heater for heating system in the body around prefabricated good insulator on the mica. Stainless steel skin and metal, tin or Tongpi produced by the thermal conductivity of. Circle plate can be made and other heterosexual products.
Mica heaters can be manufactured flat or as band heaters and are supplied either as bare mica heaters or encased in specially treated sheath materials.
ADVANTAGES of Injection Moulding machine mica heater:
The Injection Moulding machine mica heater can also be formed to shapes such as “L” or “U” sections. Holes and cut outs to customer design can be easily accommodated. Flat Mica heaters must be clamped securely to the surface to be heated.
Flat mica and flat sheathed heaters can be manufactured to almost any size. The limiting factors being the design of a suitable element tape and on large heaters, the ability to provide adequate clamping over a large surface area. Band heaters are manufactured in one piece construction up to 12” diameter.
Applications of Injection Moulding machine mica heater:
FLAT: Dies, Platens, Moulds, Tanks, Process Machinery, any application where controlled surface heating is required.
BAND: Dies, Cylinders, Drums, Tanks, Injection and Blow Moulding Machinery and Plastic Extruders.
Features: portable heater warming faster.
Table for Injection Moulding machine mica heater:
Model | Dimension(mm) | Voltage(V) | Power(W) |
LK-YM-Φ55Χ80 | Φ55Χ80 | 230 | 800 |
LK-YM-Φ120Χ141 | Φ120Χ141 | 230 | 2000 |
LK-YM-Φ120Χ51 | Φ120Χ51 | 230 | 520 |
LK-YM-Φ80Χ60 | Φ80Χ60 | 230 | 775 |
LK-YM-Φ58Χ43 | Φ58Χ43 | 230 | 250 |
LK-YM-Φ90Χ51 | Φ90Χ51 | 230 | 300 |
LK-YM-Φ185Χ51 | Φ185Χ51 | 230 | 1100 |
LK-YM-Φ130Χ66 | Φ130Χ66 | 230 | 1000 |
LK-YM-Φ165Χ66 | Φ165Χ66 | 230 | 1100 |
LK-YM-Φ160Χ70 | Φ160Χ70 | 220 | 1000 |
LK-YM-Φ230Χ90 | Φ230Χ90 | 220 | 2200 |
LK-YM-Φ154Χ94 | Φ154Χ94 | 220 | 1500 |
LK-YM-Φ152Χ100 | Φ152Χ100 | 220 | 1500 |
LK-YM-Φ180Χ80 | Φ180Χ80 | 220 | 1300 |
LK-YM-Φ265Χ75 | Φ265Χ75 | 220 | 1500 |
LK-YM-Φ90Χ180 | Φ90Χ180 | 220 | 1700 |
LK-YM-Φ90Χ60 | Φ90Χ60 | 220 | 550 |
LK-YM-Φ120Χ80 | Φ120Χ80 | 220 | 1100 |
LK-YM-Φ190Χ135 | Φ190Χ135 | 220 | 3000 |
LK-YM-Φ185Χ75 | Φ185Χ75 | 220 | 1500 |
LK-YM-Φ280Χ48 | Φ280Χ48 | 220 | 1500 |
LK-YM-Φ300Χ100 | Φ300Χ100 | 220 | 2500 |
LK-YM-Φ320Χ100 | Φ320Χ100 | 220 | 3000 |
LK-YM-Φ165Χ45 | Φ165Χ45 | 220 | 800 |
LK-YM-Φ180Χ45 | Φ180Χ45 | 220 | 900 |
LK-YM-Φ65Χ30 | Φ65Χ30 | 220 | 200 |
LK-YM-Φ230Χ45 | Φ230Χ45 | 220 | 1000 |
LK-YM-Φ55Χ100 | Φ55Χ100 | 230 | 1000 |
LK-YM-Φ80Χ70 | Φ80Χ70 | 230 | 650 |
LK-YM-Φ70Χ70 | Φ70Χ70 | 230 | 600 |
LK-YM-Φ85Χ45 | Φ85Χ45 | 230 | 530 |
LK-YM-Φ110Χ100 | Φ110Χ100 | 230 | 150 |
LK-YM-Φ102Χ70 | Φ102Χ70 | 230 | 700 |
Note: Other models are available according to your specifications. Please refer to the Order Guide |
Packaging: Fumigation free wooden case for Injection Moulding machine mica heater.
Shipment:1.small quantity by DHL,FEDEX 2.Bulk goods by Sea Freight.
Other services we are committed to offer include:
1. Flexibility with minimum order requirements
2. On-time delivery
3. Free replacement if any product quality issues within guarantee period
4. Technical support
5. Simple ordering procedure: Email, fax or mail.
DragonPower specializes in producing industrial electric heaters with a strength in R&D. Our products include air cooling & heating system, ceramic heaters, cast aluminum/copper heaters, mica heaters, cartridge heaters, infrared heaters, tubular heaters, immersion heaters, thermocouples, high temperature insulated wires & cables, etc. We provide OEM and design services.
Order Guide of Injection Moulding machine mica heater:
Please specify the following when ordering.
1.The inner diameter (mm) (or outer diameter when the heater is used inside) and length (mm) of heaters
2.width of heaters
3.Voltage and power density
4.Position and size of the hole for thermocouple
5.Wiring type and position
6.Content of the stamping if needed
7.Special gap if Necessary
8.Order quantity
9.Delivery date
* It’s better to provide us with the drawings/pictures
