Home > Lights & Lighting > LED Interior Lighting > LED Tube > 1500mm Tube LED T8 20Watt Double-input

1500mm Tube LED T8 20Watt Double-input

Name: 1500mm Tube LED T8 20Watt Double-input
Brand: BRIGHT -LED T8 8W tube
SKU: 110698471
Availability: InStock

1500mm Tube LED T8 20Watt Double-input thumbnail-1

1500mm Tube LED T8 20Watt Double-input photo-1

US$ 10 - 50 MOQ: 10 Pieces

Key Specifications

Get Latest Price

LED Light Source:

SMD3528

Warranty(Years):

Input Voltage(V):

220

Contact Supplier Request Quote Chat Now

Shenzhen Bright Technology Industrial Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

SHENGZHEN

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

LED Light Source SMD3528

Warranty(Years) 3

Input Voltage(V) 220

Lamp Power(W) 20

Lamp Luminous Flux(lm) 2000

Lamp Luminous Efficiency(lm/w) 105

Color Temperature(CCT) Other, Warm white, Pure white, Cool white

Working Temperature(℃) -20, 40

Working Lifetime(Hour) 50000

Certification CE, EMC, LVD

Place of Origin Guangdong, China

Brand Name BRIGHT -LED T8 8W tube

Model Number Other, BG-408-1500-20W, T8

Specifications

LED T8 Tube
1. 85-265V T8 Tube
2. Supper high SMD3528 LED
3. 30,000hrs
4. 5-35W T8 Tube light, 0.6--2.4Meters long

T8 led tube

We have different size: 600mm, 900mm, 1200MM, 150MM, 1800MM, 2400MM.

Description

LED Fluorescent Tube has a delicate shape, replacement of common fluorescent tube, it’s doesn’t needs to change circuit; adopt aluminum alloy as base, the shine side uses PC tube(transparent PC, ivory white frosted PC and strip PC available), The above picture is aluminum + transparent PC, diameter is φ 26mm .

T8 Light Parameters

Item NO

Wattage (W)

LED

(pcs)

Dimension

(mm)

Luminous

Flux

(LM)

Luminous Intensity

LUX

Weight(kg)

Lamp cap

Packing

(mm)

BG-409-T8-8W

144

φ26x602

792

130

0.16

G13

713*230*230

Light Source	Input Voltage	Color Rendering Index	Efficacy	Work Frequency	Constant Circuit Error	Static Power Consumption
Super Brightness LED	AC85-300V	>75%	.85%	25KHZ	<2%	<0.5W
Work Temperature	Storage Temperature	Open Protection	Short Circuit Protection	Microwave/Noise	Power Factor	Lifespan
-20 -85°C	0°C -65°C	OK	OK	<240mV	>90%	50000H

Installment Instruction(T8 holder,electronic holder,inductance holder,Japanese Ballast type Holder)

1,inductance holder installment

To unsling starter from the light before installment, fit on led Fluorescent Tube and then it lighting, the ballast could retain

2,electronic holder installment
You need to separate electric lamp holder, and remove off the inside circuit. Keep Corridor by wire, That will be OK in according with LED fluorescent installation using principle.
3,Ballast type holder installment
You need remove off the ballast and keep the path by wire. That will be OK in according with LED fluorescent installation using principle.

Luminous Intensity Graph

illumination(LUX) distance(CM)	below	deviated 1M	deviated 2M
50CM	850	35	6
100CM	210	60	13
150CM	130	62	20
200CM	70	56	24
300CM	50	32	19
Remarks: The above figures are measured based on single transparent lamp pipe 90-degree angle,for reference only.

Recommend Application Places

Uses widely in production line, station, office, family lighting, school, hospital, underground parking lot, warehouse, supermarket, advertisement lighting etc.

After Sales Service

Our LED Fluorescent Tube has three years guarantee time,Artificial damage or disconnected are out of the guarantee scope.
