Home > Lights & Lighting > LED Interior Lighting > LED Tube > 0.6m T5 LED Tube 9W

0.6m T5 LED Tube 9W

Name: 0.6m T5 LED Tube 9W
Brand: BRIGHT
SKU: 110698133
Availability: InStock

US$ 9 - 50 MOQ: 10 Pieces

Key Specifications

Get Latest Price

LED Light Source:

SMD3014

Warranty(Years):

Input Voltage(V):

220

Contact Supplier Request Quote Chat Now

Shenzhen Bright Technology Industrial Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

SHENGZHEN

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

LED Light Source SMD3014

Warranty(Years) 3

Input Voltage(V) 220

Lamp Power(W) 9

Lamp Luminous Flux(lm) 1100

Lamp Luminous Efficiency(lm/w) 105

Color Temperature(CCT) Other, Warm White,Pure White, Cool White

Working Temperature(℃) -20, 40

Working Lifetime(Hour) 50000

Certification CCC, CE, EMC, LVD

Place of Origin Guangdong, China

Brand Name BRIGHT

Model Number Other, BG-405-600-9W, BG-405-600-9W, T5

Specifications

T5 LED Tube
1.AC 85-265
2.CE and RoHS approv
3.Long Life Span--30,000hrs
4.High brightness smd3528

T5 LED Tube

Description

Adopt aluminum alloy T5 standard lamp holder.
Materail: Aluminum alloy + PC (Transparent PC, Frosted PC and Strip PC available)

Adopt super brightness Dip or SMD (3528) LED as light source; Chip brand: Epistar (made in Taiwan)
Driving by constant flow, span life is between 50000 to 80000 hours.
Input voltage: AC85V-265V

Above 70% Energy saving, almost no maintenance, without starter and ballast, fast starting ,no flashing .

T5 LED Tube

Specifications

Item No	Power	Dimension	LED Q’TY	Weight	Luminous Flux	Input Voltage	Work Frequency
BG-408-T5-3W	3W	311*16mm	42pcs	103g	230lm	AC85-265V	25KHZ
	Work Temp.	Light source	CRI	Light Efficacy	Static Power Consumption	Storage Temp.	Short Circuit Protection
	-20 -65°C	Super Bright LED	>75%	>85%	<0.15W	0 -65°C	OK
	Power Factor	Span Life	Holder	Driver Position	Open Protection	Constant Currency Error	Microwave/ Noise
	>90%	50000(hrs)	G5	External	OK	<2%	<240mV

T5 LED Tube

Illumination Intensity

illumination(LUX) distance(CM)	below	deviated 1M	deviated 2M
50CM	614	17	5
100CM	213	40	9
150CM	108	41	8
200CM	68	41	19
300CM	46	34	23
Remarks: The above figures are measured based on single transparent lamp pipe 90-degree angle, for reference only.

T5 LED Tube

Installment Instruction

1. According to the picture representation, install the match length bracket as the tube from the tube vertical direction.
2. Intervene the matching power wire to the one side (no positive and negative difference) of the bracket base as the picture shows, make the other side hang, then, connecting AC220V power and would be lighted.
3. The product could not tear down the light tube only or install other brackets to lighten, it must match our company’s bracket to use.
4. This product can’t replace the conventional T5 Fluorescent Tube.
5. This product can be used by series after put the two tubes in the bracket. At most 50 pieces in series.
6. Don’t separate this product, it’s not in the guarantee .If any error state appears, please contact with us.

T5 LED Tube

After-sale service

Any disorder appear under normal operating, we ensure to exchange within 7 days, 3 years guarantee, life-long maintenance. Any man-made damage and natural disaster is not under warranty.
