YEMOO TX2 Thermostatic Expansion Valve R22 R134a Refrigeration Expansion Valve for Sale

YEMOO TX2 Thermostatic Expansion Valve R22 R134a Refrigeration Expansion Valve for Sale thumbnail-1
YEMOO TX2 Thermostatic Expansion Valve R22 R134a Refrigeration Expansion Valve for Sale thumbnail-2
YEMOO TX2 Thermostatic Expansion Valve R22 R134a Refrigeration Expansion Valve for Sale thumbnail-3
YEMOO TX2 Thermostatic Expansion Valve R22 R134a Refrigeration Expansion Valve for Sale thumbnail-4
YEMOO TX2 Thermostatic Expansion Valve R22 R134a Refrigeration Expansion Valve for Sale photo-1
YEMOO TX2 Thermostatic Expansion Valve R22 R134a Refrigeration Expansion Valve for Sale photo-2
YEMOO TX2 Thermostatic Expansion Valve R22 R134a Refrigeration Expansion Valve for Sale photo-3
YEMOO TX2 Thermostatic Expansion Valve R22 R134a Refrigeration Expansion Valve for Sale photo-4
US$ 50 - 300 MOQ: 5 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Beijing, China
Brand Name:
Danfoss
Model Number:
TX2 thermostatic expansion valve
Contact Supplier Request Quote Chat Now
Hangzhou Yemoo Refrigeration Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai/Ningbo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Beijing, China
Brand Name Danfoss
Model Number TX2 thermostatic expansion valve
Type Other, expansion valve, TX2 thermostatic expansion valve
Application Refrigeration Parts
Certification CE



 Can I help you ?

_______________________________________________

















Why choose it ?

___________________________________________



Thermostatic expansion valves regulate the injection of refrigerant liquid into evaporators.


Injection is controlled by the refrigerant superheat.


Therefore the valves are especially suitable for liquid injection in ”dry“ evaporators where the superheat at the evaporator outlet is proportional to the evaporator load.





Features



Large temperature range


Equally applicable to freezing, refrigeration and air conditioning applications.
Interchangeable orifice assembly
– easy storage
– easy capacity matching
– better service.


Rated capacities from 0.96 to 20.5 kW (0.27 to 5.82 TR) for R407C.

Can be supplied with MOP (Max. Operating Pressure)


Protects the compressor motor against excessive evaporating pressure during normal operation.


Stainless steel bulb and Danfoss patented bulb strap


Fast and easy to install.


Good temperature transfer from pipe to bulb.


Valves for special temperature ranges can be supplied.


Design protected









What you see is what you get ?



_______________________________________________



YEMOO TX2 thermostatic expansion valve R22 R134a refrigeration expansion valve for saleYEMOO TX2 thermostatic expansion valve R22 R134a refrigeration expansion valve for saleYEMOO TX2 thermostatic expansion valve R22 R134a refrigeration expansion valve for saleYEMOO TX2 thermostatic expansion valve R22 R134a refrigeration expansion valve for saleYEMOO TX2 thermostatic expansion valve R22 R134a refrigeration expansion valve for sale







 How about it ?



_______________________________________________



T2/TE2 Thermostatic element with bulb strap
Flare x flare


Capillary tube: 1.5 m
Range N = -40 – +10 °C
Range B = -60 – -25 °C
Range NM = -40 – -5 °C MOP 0 °C
Range NL = -40 – -15 °C MOP -10 °C



 Refrigerant  Type   Pressure equalization flare Capillary      Connection      flare                    inlet x outlet Code No.
      in    mm                    Range N                                   -40~10℃ Range NM           -40~-5℃ Range NL         -40~-15℃ Range B                                  -60~-25℃
m With MOP Without MOP With MOP Without MOP With MOP Without MOP
R22 TX2 internal equalizing 1.5 3/8x1/2   10x12 O68Z3206 068Z3208 068Z3224 068Z3226 068Z3207 068Z3228
TEX2 external equalizing 1.5 3/8x1/2   10x12 068Z3209 068Z3211 068Z3225 068Z3227 068Z3210 068Z3229
R407C TZ2 internal equalizing 1.5 3/8x1/2   10x12 068Z3496 068Z3516
TEZ2 external equalizing 1.5 3/8x1/2   10x12 O68Z3501 068Z3517
R134a TN2 internal equalizing 1.5 3/8x1/2   10x12 068Z3346 068Z3347 068Z3393 068Z3369
TEN2 external equalizing 1.5 3/8x1/2   10x12 068Z3348 068Z3349 068Z3392 068Z3370
R404a/R507 TS2 internal equalizing 1.5 3/8x1/2   10x12 068Z3400 068Z3402 068Z3406 068Z3408 068Z3401 068Z3410
TES2 external equalizing 1.5 3/8x1/2   10x12 O68Z3403 068Z3405 068Z3407 068Z3409 068Z3404 068Z3411









T2/TE2 Thermostatic element with bulb strap
Flare x solder


Capillary tube: 1.5 m
Range N = -40 – +10 °C
Range NL = -40 – -15 °C
Range B = -60 – -25 °C



Refrigerant Type Pressure equalization flare Capillary Connection
 inlet (Flare) × outlet (Solder)		 Code No.
Inlet (Flare) Outlet (Solder) Range N                                  -40~10℃ Range NL         -40~-15℃ Range B                                  -60~-25℃
m inch mm mm Without MOP With MOP MOP -10°C Without MOP MOP -20°C
R22 TX2 internal equalizing 1.5 3/8 1/2 12 068Z3281 068Z3287 068Z3366 068Z3357 068Z3319
TX2 1.5 10 068Z3302 068Z3308 068Z3361 068Z3276
TEX2 external equalizing 1.5 3/8 1/2 12 068Z3284 068Z3290 068Z3367 068Z3359 068Z3320
TEX2 1.5 10 068Z3305 068Z3311 068Z3363 068Z3277
R407C TZ2 internal equalizing 1.5 3/8 1/2 12 068Z3502 068Z3329
TZ2 1.5 10 068Z3514
TEZ2 external equalizing 1.5 3/8 1/2 12 068Z3446 068Z3447
1.5 10 068Z3503 068Z3515
R134a TN2 internal equalizing 1.5 3/8 1/2 12 068Z33383 068Z3387
TN2 1.5 10 068Z3384 068Z3388
TEN2 external equalizing 1.5 3/8 1/2 12 068Z3385 068Z3389
TEN2 1.5 10 068Z3386 068Z3390
R404a/R507 TS2 internal equalizing 1.5 3/8 1/2 12 068Z3414 068Z3416 068Z3429 068Z3418 068Z3420
TS2 1.5 10 068Z3435 068Z3423 068Z3436 068Z3425 068Z3427
TES2 external equalizing 1.5 3/8 1/2 12 068Z3415 068Z3417 068Z3430 068Z3419 068Z3421
TES2 1.5 10 068Z3422 068Z3424 068Z3437 068Z3426 068Z3428














What can I get guarantee ?

_______________________________________________



1.We are Professional factory to make semi-hermetic compressor and condensing unit more than 10 years.

2.We insist on innovation,purchasing the international quality materials,strong  technique  support,strictly control the production.

3.We firmly believe quality first,perfect production responsibility system.

4.We promise all Yemoo brand products,we supply 3 months new products guarantee replacement,12 months quality guarantee service.



So,what Yemoo can support you ? It's best price ratio products,perfect after-sales service guarantee.

Yemoo's value is what we supply you is not only products,but also creating you most value.
