Why choose it ?
___________________________________________
All ELIMINATOR driers have a solid core with binding material held to an absolute minimum. There are two types of ELIMINATOR cores. Type DML driers have a core composition of 100% Molecular Sieve, while type DCL contain 80% Molecular Sieve with 20% activated alumina.
ELIMINATOR type DML driers are designed for applications requiring the highest moisture capacity. ELIMINATOR type DCL driers are designed for applications requiring the high moisture capacity and acid adsorption capacity.
Available with solder(cu-plated steel connectors) and flare connections. For other connections please contact your Danfoss Sales Representative.
Features
The core type DML
100% Molecular Sieve core
High drying capacity minimizing the risk of acid formation(hydrolysis)
Recommended for use with HFC and HCFC refrigerants
Will not deplete oil additives
The core type DCL
80% Molecular Sieve with 20% activated alumina
Prefect core blend for systems that operate at high condensing temperatures and require high drying capacity
Recommended for use with HFC and HCFC refrigerants
The shell
PED approved for PS 46 bar
Available with solder(Cu-plated steel connectors) and flare connections
Corrosion resistant powder-painted finish. Special coating for marine applications available upon request
Allows installation with any orientation provided the arrow is is the flow direction
Available in sizes 3-75 cubic inches
The filter
25 μm(0.001 inch) filter provided high retention with minimal pressure drop
Thermally stable up to 120℃
What you see is what you get ?
_______________________________________________
How about it ?
_______________________________________________
| Type DCL Flare | ||||
| Type | Connection size | Multi pack | ||
| inch | mm | Code no. | Qty | |
| DCL 032* | 1/4 | 6 | 023Z5000 | 32 |
| DCL 032 | 1/4 | 6 | 023Z5075 | 32 |
| DCL 033* | 3/8 | 10 | 023Z5001 | 32 |
| DCL 033 | 1/4 | 10 | 023Z5089 | 32 |
| DCL 052 | 1/4 | 6 | 023Z5002 | 24 |
| DCL 053 | 3/8 | 10 | 023Z5003 | 24 |
| DCL 082 | 1/4 | 6 | 023Z5004 | 24 |
| DCL 083 | 3/8 | 10 | 023Z5005 | 24 |
| DCL 084 | 1/2 | 12 | 023Z5006 | 24 |
| DCL 162 | 1/4 | 6 | 023Z5007 | 12 |
| DCL 163 | 3/8 | 10 | 023Z5008 | 12 |
| DCL 164 | 1/2 | 12 | 023Z5009 | 12 |
| DCL 165 | 5/8 | 16 | 023Z5010 | 12 |
| DCL 166 | 3/4 | 19 | 023Z5011 | 12 |
| DCL 303 | 3/8 | 10 | 023Z5012 | 8 |
| DCL 304 | 1/2 | 12 | 023Z5013 | 8 |
| DCL 305 | 5/8 | 16 | 023Z5014 | 8 |
| DCL 306 | 3/4 | 19 | 023Z0156 | 8 |
| DCL 413 | 3/8 | 10 | 023Z0101 | 8 |
| DCL 414 | 1/2 | 12 | 023Z0102 | 8 |
| DCL 415 | 5/8 | 16 | 023Z0103 | 8 |
| *Wire mesh in filter drier outlet | ||||
| Type DML Flare | ||||
| Type | Connection size | Multi pack | ||
| inch | mm | Code no. | Qty | |
| DML 032* | 1/4 | 6 | 023Z5035 | 32 |
| DML 033* | 3/8 | 10 | 023Z5036 | 32 |
| DML 033 | 3/8 | 10 | 023Z5090 | 32 |
| DML 052 | 1/4 | 6 | 023Z5037 | 24 |
|
DML053 |
3/8 | 10 | 023Z5038 | 24 |
| DML 082 | 1/4 | 6 | 023Z5039 | 24 |
| DML 083 | 3/8 | 10 | 023Z5040 | 24 |
| DML 084 | 1/2 | 12 | 023Z5041 | 24 |
| DML 085 | 5/8 | 16 | 023Z5073 | 24 |
| DML 162 | 1/4 | 6 | 023Z5042 | 12 |
| DML 163 | 3/8 | 10 | 023Z5043 | 12 |
| DML 164 | 1/2 | 12 | 023Z5044 | 12 |
| DML 165 | 5/8 | 16 | 023Z5045 | 12 |
| DML 166 | 3/4 | 19 | 023Z5046 | 12 |
| DML 303 | 3/8 | 10 | 023Z0049 | 8 |
| DML 304 | 1/2 | 12 | 023Z0050 | 8 |
| DML 305 | 5/8 | 16 | 023Z0051 | 8 |
| DML 306 | 3/4 | 19 | 023Z0193 | 8 |
| DML 413 | 3/8 | 10 | 023Z0108 | 8 |
| DML 414 | 1/2 | 12 | 023Z0109 | 8 |
| DML 415 | 5/8 | 16 | 023Z0110 | 8 |
| *Wire mesh in filter drier outlet | ||||
What can I get guarantee ?
_______________________________________________
1.We are Professional factory to make semi-hermetic compressor and condensing unit more than 10 years.
2.We insist on innovation,purchasing the international quality materials,strong technique support,strictly control the production.
3.We firmly believe quality first,perfect production responsibility system.
4.We promise all Yemoo brand products,we supply 3 months new products guarantee replacement,12 months quality guarantee service.
So,what Yemoo can support you ? It's best price ratio products,perfect after-sales service guarantee.
Yemoo's value is what we supply you is not only products,but also creating you most value.
