Specifications
Ceramic heater plugs:1.industry ceramic plug
2.High temperature resistance
3. 110V-600V
4. ceramic or silicone available
Specification of ceramic heater plugs:
a. Silicone rubber /Silastic shell can resist high temperature,below 300 C and resist high voltage(220V~600V). 25A can resist acid,alkali and smash.
b. Special aluminum alloy shell is introduced overseas data and produced. High temperature resistance,below 500 °C; High voltage resistance(220V~600V);Long use life.
Silicone Plug |
Aluminum Alloy Plug |
|
Plug body material |
Silicone rubber /Silastic shell |
Aluminum Alloy shell |
Voltage |
220V - 600V |
220V - 600V |
Current Amp |
25A |
35A |
Plug heat resistance |
Under 300°C |
Under 500°C |
Cooper Hole |
5mm, 6mm |
5mm, 6mm |
Ceramic heater plugs is made of copper core and ceramic, outside is made of metal aluminum protection shell or silicone rubber protection shell. Used as lead wire under 300°C working environment.Different material for high temperature plug as alloy aluminum shell and silicone rubber shell, it is designed for plug style electric heating element, diameter is from 4mm to 6mm .Many advantages such as High strength, Heat-resistant, Large current (3A~35A), Long use-life etc. Therefore it solves the problem as common bakelite shell plug is not heat-resistant, needs replace normally.
Features of ceramic heater plugs:
1.Special heat-resistant ,high strength aluminum alloy shell is made of import foreign equipment. Heat-resistant, under 500°C,withstand voltage as 200V~600V,long use-life, diameter of hole as 4mm,5mm and 6mm.
2.Silicone rubber shell is heat-resistant, under 200°C,withstand voltage as 220V~600V.25A soft fluorous rubber connection is acid proof,alkali proof, broken proof, diameter as 4mm,5mm,6mm,guarantee quality, long use-life.
Application of ceramic heater plugs:
Widely used in Rubber Machine, Food Machine ,Chemical ,Electric wire etc, and kinds of industry , high temperature power connection wire of kinds of plug style electric heating element.
Plastic bag and paper carton or wooden case for ceramic heater plugs
Customized service
One to two years warranty period
Professional purchasing guid
Technial support
Located in Yancheng, Jiangsu, DRAGONPOWER covers an area of 27,000 square meters. Since 1978, DRAGONPOWER has been accumulating its experience in industrial heater market. Centered by superior quality, motivated by technical innovation, and oriented by excellent services, DRAGONPOWER provides optimum heating solutions for different applications, to satisfy requirements of worldwide top class customers and fast-growing customers with great potential.
Our advantages:
We have got 9 patents on our products, and the latest one is on the product of electromagnetism induction heaters.
We have famous professor team responsible for D & R, cooperated with best university in China.
We are one of the largest and most famous manufacturers in industrial heaters, with more than 40 years manufacturing experience.
All of our raw material came from the big corporations, and have strict control on raw material and manufacturing process.
We cooperate with the most famous equipment manufacturers in the world, and grow with them.
6. The equipment we used is the most advanced in the field.
Order guides of ceramic heater plugs:
Matched pin size:4mm,5mm,6mm?
Voltage
Current
Order quantity
Package requirements
Lead time requirements
