energy saving economical solar cold room storage with solar panel power supply
- 1000 Set / Sets per Month
- Shanghai or Ningbo
- T/T
- fresh Vegetable/fruit and meat cold storage warehouse
- Blast Freezer quick freezing for fish meat Ice Cream CE Approval
- vegetable/ fruits /meat/ beef quick freeze warehouse 200mm
- frozen cold room for meat and fish with solar power cold room thermometer
- Quick Frozen Cold Room for Pizza/Meat/Fish/Chicken/Vegetable
- frozen beef cold storage cold chain cold warehouse
Product Details
Condition: | New | Temperature: | 20℃ to - 45℃ | Place of Origin: | Zhejiang, China |
Brand Name: | Yemoo(solar cold room) | Model Number: | YMCR | Voltage: | 220V~240V,380V~420V |
Power(W): | According to user requirements | Dimension(L*W*H): | According to user requirements | Weight: | According to user requirements |
Certification: | CE,CCC,ISO9001 | Warranty: | 1 Year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Range of application
-Vegetable, Fruit, Meat, Seafood, Medical, Agricultural, Chemical industry, Restaurant, etc.
Feature of solar cold room
(1) Temperature : 20℃ to - 45℃( According to user requirements )
(2) Size: Customization.
(3) Functions: for the Meat /Fish /Vegetable fresh keeping, and generally using in Food processing factory ,supermarket, and hotel etc.
(4)Excellent quality, stable performance
Components:
(1) Condensing unit: Bitzer, Copeland, Maneurope (Danfoss),Yemoo,etc.
(2) High efficiency air-coolers
(3) Insulation Panel: PU panel
(4) Other accessories: world-famous brands, like Danfoss, Castle, Electric Control: Siemens, Schneider, CHNT, etc.
Product information of solar cold room
Dimension | Length (m) *Width (m)*Height (m). customized |
Panel | polyurethane insulation panel,38~46kg/m3, fire resistance |
Foaming material | BASF |
Panel thickness | 100mm, 120mm,150mm optional |
Steel cover | painted galvanized steel(stucco embossed aluminum, stainless steel, PVC stell optional). |
Panel connection | cam lock type, use hexagonal key to assemble and disassemble |
Type of door | hinge door, convex door, sliding door |
Temp.of cold room | -45~+20oC degree, optional, can be mixed temp in a project. |
Refrigeration unit | Bitzer, Copeland, Maneurope (Danfoss),Yemoo,etc. |
Refrigeration type | air cooled / water cooled, R134a, R404a, R507a or R22 |
Fittings | all necessary fittings are included, optional.. |
Place to assemble | indoor/out door(concrete construction building/steel construction building). |
Voltage | 220V/50HZ, 220V/60HZ, 380V/50HZ optional. |
Panels are joined together by means of tongue and groove and locked together by camlock on each side of the panel to ensure air tight joints.
-High density thermo insulated panel ranges from 38~46kg/m3 for perfect solar cold room heat insulation efficiency.
-Low flammable PU foaming material is used in the panel of solar cold room
-Cam-lock design fastener to install solar cold room tightly and strongly
-Silica gel are used on the panel edge of the joint parts of each sandwich panel to ensure perfect sealing to avoid the cooling air leakage from the solar cold room or moisture inside the PU insulated panel for the best refrigeration and solar cold room result.
Testing Specification of solar cold room
No. | Inspection Item | Unit | Technology requirement | Inspection result |
1 | Density | kg/m3 | 38~46 | 43 |
2 | Compressing strength(10%deformation) | Kpa | ≥ 160 | 200 |
3 | Bending Strength | Kpa | ≥ 245 | 331 |
4 | Absording rate | % | ≤ 4 | 3 |
5 | Heating coefficient | W/m.k | 0.024 | 0.021 |
6 | Average burning time(vertical) | S | ≤ 30 | 3 |
7 | Average burning height(vertical) | s | ≤ 250 | 250 |
-Multiple types of optional thermo insulated panel solar cold room doors (Convex hinged door/Hinged door/Sliding door) with customized door size.
Thickness of PU panel | Application temperature |
100mm | -5°C or above |
120mm | -18°C or above |
150mm | -25°C or above |
Doors:
1).Swing door and Sliding door available.
2).Swing door: Manual, Automatic available etc.
3).Door panel made with special pressing technology PU material.
4).Door frame: color steel or stainless steel.
5).With Heater and anti-stuck system.
Door of solar cold room for your optional:
No | Door type | Door size( stock size )
| Door heater voltage |
1 | Flush mounted hinged door | 800mm W*1900mm H | 24V / 36V |
2 | not flush mounted hinged door | 832mm W*1860mm H | 24V / 36V |
3 | sliding door | 832mm W*1860mm H | 24V / 36V |
4 | glass door | 725W*1775 mm | 24V / 36V |
1.We are Professional factory to make semi-hermetic compressor and condensing unit more than 10 years.
2.We insist on innovation,purchasing the international quality materials,strong technique support,strictly control the production.
3.We firmly believe quality first,perfect production responsibility system.
4.We promise all Yemoo brand products,we supply 3 months new products guarantee replacement,12 months quality guarantee service.
So,what Yemoo can support you ? It's best price ratio products,perfect after-sales service guarantee.
Yemoo's value is what we supply you is not only products,but also creating you most value.
