Home > Lights & Lighting > LED Lighting Decoration > LED Strip Light > SMD 3528 LED Strip 1200leds per Roll 3000K
US$ 1 - 2
MOQ: 5 Meters
Key Specifications
Get Latest Price
LED Light Source:
5050
Type:
Flex LED Strips
Input Voltage(V):
12/24V DC
Payment & Shipping
Payment Methods:
Port of Shipment:
SHENZHEN
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
High Lumen 5050 SMD LED Strip 60led/m, White PCBUS$ 1 - 2MOQ: 5 Meters -
12V Dimmable LED Strip Lighting 3528NegotiableMOQ: 5 Rolls
-
Warm White 3000K LED Strip 12V 5050US$ 1 - 2MOQ: 5 Meters
-
Color Temperature Adjustable Dimmable Flexible LED StripsNegotiableMOQ: 5 Rolls
-
10M/Roll LED 3528 240 Led/m StripUS$ 1 - 2MOQ: 5 Meters
LED Light Source
5050
Type
Flex LED Strips
Input Voltage(V)
12/24V DC
Lamp Power
24
Lamp Luminous Flux(lm)
1500
Color Temperature(CCT)
Warm White
Working Temperature(℃)
-20, 40
Working Lifetime(Hour)
30000
Lamp Body Material
Copper
Certification
CE, EMC, FCC, LVD
Emitting Color
Changeable
Place of Origin
Guangdong, China
Brand Name
OEM ODM
Model Number
Flexible led strip, led ribbon
Specifications
LED Strip1.30000 hrs.
2.Super Bright LED light source.
3.Waterproof or Non
4.DC12V/24V
LED Strip :
1.Super bright LED light source,customized LED qty and length.
2.Single colour,RGB,full spectrum with outer remote controller.
3.Digital LED strips can realise many kinds of flashing models like gradual changing chasing flowing and so on.
4.DC 12/24Vconvenient to install.
5.Waterproof(IP67) and non-waterproof available.
6.Many types of self-developed accessories such as the fixed clip,
terminals and etc.
7.The life span is over 30000 hour.
8.Application:Architecture decorating.channel letters,advertising billboards,marketplace,cars,KTV,and so on.
9.Sample required: Sample is available, but customer must pay for the sample price and shipping costs.
10.Sample delivery time: About 3-5 days for standard model and 8-9 days for OEM production or customer's designs.
| NO. | VOLTAGE(V) | POWER(W) | LED TQY, | LED TYPE | LEMENS FLUX(Lm)(white) |
| Non-Waterproof Series | |||||
| BG-105-3528-150 | DC12 | 2.4 W | 30 pcs/m | SMD3528 | 150 Lm |
| BG-106-3528-300 | DC12/24 | 4.8 W | 60 pcs/m | SMD3528 | 305 Lm |
| BG-107-3528-600 | DC12/24 | 9.6 W | 120 pcs/m | SMD3528 | 600 Lm |
| BG-108-3528-1200 | DC24 | 14.4 W | 240 pcs/m | SMD3528 | 1100 Lm |
| BG-112-5050-150 | DC12/24 | 6 W | 30 pcs/m | SMD5050 | 426 Lm |
| BG-113-5050-300 | DC12/24 | 12 W | 60 pcs/m | SMD5050 | 845 Lm |
| BG-131-335-300 | DC12/24 | 4.8 W | 60 pcs/m | SMD335 | 550 Lm |
| BG-131-335-600 | DC12/24 | 8.2 W | 99 pcs/m | SMD335 | 800 Lm |
| BG-131-335-600 | DC12/24 | 9.6 W | 120 pcs/m | SMD335 | 1030 Lm |
| IP65 Soft silicon Waterproof Series | |||||
| BG-105A-3528-150 | DC12 | 2.4 W | 30 pcs/m | SMD3528 | 142 Lm |
| BG-106A-3528-300 | DC12/24 | 4.8 W | 60 pcs/m | SMD3528 | 300 Lm |
| BG-107A-3528-600 | DC12/24 | 9.6 W | 120 pcs/m | SMD3528 | 588 Lm |
| BG-108-3528-1200 | DC24 | 14.4 W | 240 pcs/m | SMD3528 | 1100 Lm |
| BG-112A-5050-150 | DC12/24 | 6 W | 30 pcs/m | SMD5050 | 415 Lm |
| BG-113A-5050-300 | DC12/24 | 12 W | 60 pcs/m | SMD5050 | 830 Lm |
| BG-131A-335-300 | DC12/24 | 4.8 W | 60 pcs/m | SMD335 | 520 Lm |
| BG-131A-335-600 | DC12/24 | 9.6 W | 120 pcs/m | SMD335 | 980 Lm |
| IP66 Silicone Tube Waterproof Series | |||||
| BG-105B-3528-150 | DC12 | 2.4 W | 30 pcs/m | SMD3528 | 145 Lm |
| BG-106B-3528-300 | DC12/24 | 4.8 W | 60 pcs/m | SMD3528 | 282 Lm |
| BG-107B-3528-600 | DC12/24 | 9.6 W | 120 pcs/m | SMD3528 | 565 Lm |
| BG-108B-3528-600 | DC24 | 14.4 W | 240 pcs/m | SMD3528 | 1050 Lm |
| BG-112B-5050-150 | DC12/24 | 6 W | 30 pcs/m | SMD5050 | 422 Lm |
| BG-113B-5050-300 | DC12/24 | 12 W | 60 pcs/m | SMD5050 | 820 Lm |
| BG-131B-335-300 | DC12/24 | 4.8 W | 60 pcs/m | SMD335 | 520 Lm |
| BG-131B-335-600 | DC12/24 | 9.6 W | 120 pcs/m | SMD335 | 980 Lm |
| IP68 Soft silicon tube+epoxy | |||||
| BG-105C-3528-150 | DC12 | 2.4 W | 30 pcs/m | SMD3528 | 145 Lm |
| BG-106C-3528-300 | DC12/24 | 4.8 W | 60 pcs/m | SMD3528 | 282 Lm |
| BG-107C-3528-600 | DC12/24 | 9.6 W | 120 pcs/m | SMD3528 | 565 Lm |
| BG-112C-5050-150 | DC12/24 | 6 W | 30 pcs/m | SMD5050 | 422 Lm |
| BG-113C-5050-300 | DC12/24 | 12 W | 60 pcs/m | SMD5050 | 820 Lm |
| BG-131C-335-300 | DC12/24 | 4.8 W | 60 pcs/m | SMD335 | 520 Lm |
| BG-131C-335-600 | DC12/24 | 9.6 W | 120 pcs/m | SMD335 | 980 Lm |
| IP66 Digital ( DMX signal) LED Strip Silicone Tube Waterproof Series | |||||
| BG-210B-5050-150 --IC | DC12 | 7 W | 30 pcs/m | SMD5050 | ----------------- |
| BG-210B-5050-210 --IC | DC12 | 9.6 W | 42 pcs/m | SMD5050 | ----------------- |
