copper cable lug with two holes
- 0 per Month
- any port in china
- T/T Credit Card
Product Details
Place of Origin: | Hunan, China | Brand Name: | changlan | Model Number: | DT |
Type: | Lug |
Product Description
Specifications
copper cable lug with two holes:good quality of material
advanced processing technology
copper cable lug with two holes :
Type: DL
Specification:
Cable cross section | d | D | Ø | L | L1 | H | |
Uncompression | Compression | ||||||
10 | Ø4.5 | Ø4.5 | Ø7.5 | 6.5 | 60 | 31 | 2.5 |
16 | Ø6 | Ø6 | Ø9 | 8.4 | 65 | 32 | 2.5 |
25 | Ø7 | Ø7 | Ø10 | 8.4 | 66 | 32 | 3 |
35 | Ø9 | Ø9 | Ø12 | 8.4 | 70 | 36 | 3.5 |
50 | Ø10 | Ø10 | Ø14 | 10.5 | 80 | 40 | 4 |
70 | Ø12 | Ø12 | Ø16 | 10.5 | 84 | 42 | 4.5 |
95 | Ø14 | Ø13 | Ø18 | 13 | 92 | 44 | 5 |
120 | Ø16 | Ø15 | Ø21 | 13 | 100 | 46 | 5.5 |
150 | Ø17 | Ø16 | Ø23 | 13 | 106 | 50 | 6 |
185 | Ø19 | Ø18 | Ø25 | 13 | 113 | 52 | 6.5 |
240 | Ø21 | Ø20 | Ø28 | 13 | 122 | 56 | 7 |
300 | Ø24 | Ø22 | Ø31 | 17 | 131 | 58 | 8 |
400 | Ø27 | Ø25 | Ø35 | 17 | 140 | 62 | 9 |
500 | Ø30 | Ø29 | Ø40 | 17 | 143 | 65 | 10 |
630 | Ø34 | Ø32 | Ø47 | 17 | 156 | 72 | 12 |
800 | Ø38 | Ø36 | Ø54 | 17 | 176 | 86 | 14 |
