DC 12V RGBW LED SMD 5050 Strip

Shenzhen Bright Technology Industrial Ltd.
DC 12V RGBW LED SMD 5050 Strip thumbnail-1
DC 12V RGBW LED SMD 5050 Strip thumbnail-2
DC 12V RGBW LED SMD 5050 Strip photo-1
DC 12V RGBW LED SMD 5050 Strip photo-2
US$ 1 - 7.5 MOQ: 1 Roll
Key Specifications
Get Latest Price
LED Light Source:
SMD5050
Type:
Flex LED Strips
Input Voltage(V):
12V/24VDC
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
SHENZHEN
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
LED Light Source SMD5050
Type Flex LED Strips
Input Voltage(V) 12V/24VDC
Lamp Power 19
Lamp Luminous Flux(lm) 1700
Color Temperature(CCT) RGBW
Working Temperature(℃) -20, 40
Working Lifetime(Hour) 50000
Lamp Body Material Copper
Certification CE, EMC, FCC, LVD
Emitting Color Changeable
Place of Origin Guangdong, China
Brand Name RGBW led strip 5050
Model Number BG-214-5050-300

RGBW 4 color LED Strip 5050, 60led/m, DC12/24V





MODEL NO.: BG-214-5050-300







FEATURES:





1.  Width: 12mm, 5m/reel;



2.  Viewing angle : 120 degrees;



3.  DC12V:Cuttable at 3 leds; DC24V:Cuttable at 6 leds



4.  Color available:Four color;



5.  Assembled with 300 pcs SMD5050 / 5 meter packing;



6.  Long life: 50,000 hours;



7.  Board material: FPC;



8.  Input: DC 12/24V;





PICTURES:

DC 12V RGBW LED SMD 5050 Strip



Specifications:



Light Color

RGB+White(WW/NW/W/CW)

LED Quantity

SMD5050 60 pcs/m

Input Voltage

12/24V DC

Operating Current

1.6A/0.8A

Input Power

19W

Water Proof

IP20/IP66/IP68

Lumens

1700 Lm/meter

Size

5000mmX12mm

View Angle

120°

Illumination range

0.5-1.5 m

Storage Temperature

-40℃----+80℃

Operating Temperature

-25℃----+60℃







Pictures:

DC 12V RGBW LED SMD 5050 Strip

 DC 12V RGBW LED SMD 5050 StripDC 12V RGBW LED SMD 5050 StripDC 12V RGBW LED SMD 5050 StripDC 12V RGBW LED SMD 5050 Strip

DC 12V RGBW LED SMD 5050 Strip





Warning:

      1. Supply voltage of this product is DC12V; never connect to other high voltage.

      2. Never connect two wires directly in case of short circuit.

      3. Lead wire should be connected correctly according to colors that connecting diagram offers.

4. Warranty of this product is 2 years, in this period we guarantee replacement or repairing with no charge, but exclude the artificial situation of damaged or overload working.



APPLICATIONS:

1) Indoor and outdoor decorative lighting and backlighting

2) Emergency hallway lighting

3) Auditorium walkway lighting

4) Outdoor illuminated signs and advertisements





Packing:

DC 12V RGBW LED SMD 5050 Strip



Applications:



Widely used indoor and outdoor lighting, such as room, office, KTV, Bar, wall edge, sink, conceal, ceiling,

backlight for indoor lighting, and architecture, sign, advertisement, path, gallery etc for outdoor lighting.





 Indoor applications:



 DC 12V RGBW LED SMD 5050 Strip





DC 12V RGBW LED SMD 5050 Strip





Our office building:

DC 12V RGBW LED SMD 5050 Strip



Express Delivery:



  DC 12V RGBW LED SMD 5050 Strip



Payment Terms:



1.T/T (in advance)

2.Paypal

3.Western Union
