Ahouse 2015 Window Opener Automatic

Name: Ahouse 2015 Window Opener Automatic
Brand: Ahouse
Availability: InStock

FOB Price

US$ 1 - 135 / Set

10 Sets(Min. Order)

Port zhongshan port
Payment TermsCredit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Guangdong, China	Brand Name	Ahouse
Model Number	TC3	Frame Material	Other, Stainless steel
Open Style	Automatic	Type	Other, Window
Opening Pattern	Horizontal

Product Description

Main Feature:

1. DC 24V low voltage motor for maximum safety.

2. Piston stroke can be manually cut-off feature.

3. Build-in over current safety cut-off feature.

4. Suitable for all dimensions of vent window and roof light.

5. Build-in control system,easy installation.

6. Can be controlled by wall switch or remote control,control group by one remote control.

7. Various piston stroke to be selected.

8. Complete supporting bracket kit,suitable for all window type.

Electric:
Power supply	AC 110V-240V
Operating voltage	DC 24V
Controller	Build-in controller
Safety detection	Over current detection
Optional device	Heat detector/smoke detector/push button/synchronizer
IP rating	IP66

Mechanical:
Model	TC3
Max.piston stroke	300mm
Max.length of motor	900mm
Max.force	1000 N
Frame housing	Stainless steel
Driving method	Screw driven piston type
Openign degree	0~65 Degree
Stroke speed	30mm/s
Temperature	-25°C to +50°C

Suitable for Window's Size and Weight:
Height of window	700mm
Width of window	3000mm
Weight of window	80kg

The Benefits of using a Ahouse winodw actuator are:

DC24V motor with buil-in control board

Solar panel can be optional

Can be controled by remote control, push button,etc...

Compact, completely enclosed storage position.

Completely protected from weather when not in use.

Optional Wind Sensor.

The automatic window Operator meets the highest standards in safety. To begining with, the automatic window Operator series had met CE and IP66 standard. The diligent observation of safety standards ensures that window Opener not only meets satefy requirements, but also offers superior quality. Simplest and Safest installation instuction.
