Product Details
Place of Origin: | Zhejiang, China | Brand Name: | Dibsys | Model Number: | RF to IP Transcoder solution |
Product Description
Dibsys Solution for DVB-S2 to IP Transcoder
Solution 1
◆ENC3580
6* DVB-S2/C/T tuners input
8*SPTS & 1*MPTS (UDP and RTP/RTSP) output; 2 ASI output
Solution 2
◆Caster-T323
8 FTA DVB-S2 Tuners input
Transcode up to 20 SD or 10x720P or 5-6 Full HD Channels
UDP, RTSP, RTMP, HTTP, HTTP Live Smooth(HLS), FTP Protocol IP Output
Solution 3
Compared with a device integrated DVB-S2 receiver and transcoder Using DVB-S2/IP gateway (IRD1218) and IP / IP Transcoder (Caster-T328) two separate devices connected to IP networks, will make the two devices play a more independent advantages. Therefore, it will enhance the performance of the entire transcoder and reduce the costs.
◆IRD1218
8 FTA DVB-S/S2/C/ISDB-T/ATSC RF inputs
Up to 244 SPTS/14 MPTS over IP out
MPEG-TS over RTP/UDP out
◆IRD1380
8xTuners Input, options DVB-T2/T/S2/S/C/DTMB/ATSC/ISDB-T
8×DVB-CI Slots, multi-program decryption, BISS-1 and BISS-E decryption
◆Caster-T328
Transcode up to 200+ SD Channels
UDP, RTSP, RTMP, HTTP, HTTP Live Smooth(HLS), FTP Protocol IP Output
1.8 FTA DVB-S/S2 RF In
2.up to 200+ SD Streams out
3.Ultra-Low bitrate
4.MPEG2 to MPEG4/H.264 or h.264 to mpeg2/h.264 Trascoder, Scaler, Stream
5.Multi-Sceen out per the same video source in
6.Supports RTMP, HTTP, Smooth and Live Streaming and Works with Wowza, Adobe Flash Server
7.Audio Support AAC, MPEG-1 Layer II, Dolby Digital AC-3.Optional MP3, Supports Adaptive Bitrate Streaming, HLS, RTMP, and HTTP.
8.Any to Any resolution
9.LOGO Insertion
1.More stable and reliable, and scalable
2.Make transcode itself achieve the highest efficiency,and optimize latency transcoding.
3.More cost savings. Take IRD1218 for an example, it has 8 tuners, if every tuner has 38Mbps data streams and 10 programs, which makes it 300mbps Bitrate and 80 programs in total. That means you can share one IRD1218 for 4 transcoders to use.
4.Arrange programs to any named transcoder, so that HD programs works in one transcoder, and SD programs works in another transcoder, which makes the efficiency of the transcoder perform the best.
5.Except for transmitting DVB-S2/IP streams to trascoder, it can also be used for other purposes. (detecting, DVB broadcast headend)
6.Easy to Maintenance and Management System, Even one IRD fails, it will not lead to another transcodes stop working.
Technical Data
Packing
Delivery
