Advanced H.265 HEVC Encoder and Transcoder
Overview
CASTER-T340 is Dibsys independent R & D product with a high performance and multi-function SD/HD encoder
which using standard 1RU chassis structure, based on FCPC collaborative computing platform, is a broadcast
high-quality video and audio real-time encoding and transcoding products. Video codec Supports standardsincluding
H.264/AVC, H.265/HEVC, MPEG2, MPEG4, and the audio codec supports standards including MP2,MP3AAC, AC3.
CASTER-T340 embedded processing module and collaborative computing power, video and audio signals can be
real-time encoding and transcoding implementation of low bit rate and high quality.
CASTER-T340 Supports many video/audio input and output interface standards, including IP,ASI, SDI, HDMI, AV
interface(CVBS) input signal, the highest rate of IP MPEG-TS single program output is 20Mb/s , and highest rate of
ASI and IP MPEGTS multi-program output is 200Mb/s. It has a variety of business SDI, HDMI original video decode
audio signal output, gateway interface supports unified, can be encoded, and configuration of multiple signal decoding,
transcoding, with simple operation, strong function, and suitable for radio and TV and streaming media applications
And can provide comprehensive low bit rate for the user, digital audio and video coding and high quality, one-step
solution of encoding, transcoding, decoding.
Key Features
l Optimized for 500 Kbps for 480i/576i, 1.5 Mbps for HD 720p, 2.5 Mbps for HD 1080i and 3.5 Mbps for HD 1080p.
l Using standard 1RU chassis, core with the FPGA matrix, CPU, GPU as the parallel processing technique assisted collaborative.
l Embedded Web Server, support the unified configuration operation of remote web page after login.
l Support 2 channels Full HD or 8 channels SD or user-defined type real-time encoding and transcoding.
l Support SDI, ASI, IP, HDMI, CVBS input
l Adopting the module slot design, according to the actual needs of users, can be extended to 6 modules
l Support IP MPEGTS single program output and ASI, IP MPEGTS multi program output.
l Support MP2, MP3, AAC, AC3 and other audio codec standards
l Support mpeg2/mpeg4/h.264/h.265(HEVC)
l video codec rate 50k-5Mbps,audio rate 8k-384kbps
l Full HD (1920*1080), high definition (1280*720), standard definition (720*576, 720*480), CIF, QCIF or a custom video
encoding/decoding resolution.
l Supports 10, 16, 24, 25, 30, 50, 60 video coding rate.
l support five grade video coding rate of adjustment.
l Support CAVLC,CABAC entropy coding mode selection, motion estimation search range setting and de-interlacing
algorithm selection.
l Support CBR, VBR rate control mode.
l Support same input source mapping multi-resolution, bitrate, Codec, protocol, interface output.
l Perfect fault alarm record query.
l Redundant power (optional).
Technical specifications
Our advantages
2) 3-year warranty
3) Perfect after-sale service and technical support
