8-channel Professional Digital Cable TV and Satellite tv Decoder With Composite AV Out, 2 Tuner/IP and ASI Inputs

8-channel Professional Digital Cable TV and Satellite tv Decoder With Composite AV Out, 2 Tuner/IP and ASI Inputs thumbnail-1
8-channel Professional Digital Cable TV and Satellite tv Decoder With Composite AV Out, 2 Tuner/IP and ASI Inputs photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
Dibsys
Model Number:
IRD1208
Contact Supplier Request Quote Chat Now
Hangzhou DIBSYS Technologies Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai/Hangzhou
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name Dibsys
Model Number IRD1208
Product Description

8ch Satellite FTA Receiver and Decorder


IRD1208 is a multi-channel professional FTA receiver and decoder with broadcast-quality launched by DIBSYS. This was designed for demodulating and decoding up to eight unscrambled SD MPEG-2, AVC and AVS programs.

It supports a wide range of input and output options, coming from DVB-S/S2 satellite, Ethernet network and local DVB-ASI interface, allowing it handle any program sources, decoding output via analog composite video and unbalanced or balanced audio interfaces. It is also highly versatile and can decode up to eight channels SD MPEG-2, AVC, AVS programs in one rack unit.

The IRD1208 supports Web browser for local and remote management and maintenances, this can significantly reduce management time and operating expense (OPEX) of operators.


Feature


1.Versatile functions- Support DVB-S/S2 RF reception &demodulation, IP and DVB-ASI mpeg-ts inputs. Unbalanced or balanced analog audio out in 1RU or 2RU chassis

2.High density-Up to 8 channels of standard definition video and audio decoding out

3.Multiple vieo decoding-The standard configurations, no additional charge in software license including MPEG-2,MPEG-4 AVC and AVS

4.High reliability and stability-Benefit from highly reliable hardware and software design,adopts the third generation motherboard built-in discrete function module desgn for fast replacement of failure functions module multiple protective mechanisms are introduced, such as power failure memory recovery,over-voltage,over-load,short-circuit protection

5.Improved User Operation Efficiency-Support remote software upgrades, Convenient management and maintenance via Web browser

RF Tuner input
Comply to DVB-S/S2, DVB / DSS standard
Input frequency range: 950～2150MHz
Input level: -25～-65dBm
Connector: F-female type, 75ohm
Symbol rate: 2-45Msps for QPSK;10-31Msps for 8PSK
Rolling off factory:0.35 for QPSK;0.35,0.25,0.2for 8psk
Convolution encoding Rates:
DVB-S QPSK: 1/2, 3/5, 2/3, 3/4, 4/5, 5/6, 8/9, 8/10 ;
DVB-S2 8PSK: 3/5, 2/3, 3/4, 5/6, 8/9, 9/10
2 channels RF inputs and loop out
LNB Power Output: 0V/+DC 13V/18V
ASI Input
1x ASI input,BNC, impendence: 75Ω
comply to EN50083-9, ASI standard
188 bytes per packet
Bitrate: ≤100mbps
MPEG-TS OVER IP Input(option)
100/1000M base-T,Full Duplex,RJ45
Bit rate: ≤800Mbps
Data Protocol: UDP, Multicast/Unicast(IGMPv1,V2
Video Decoding
Decoding Profile&Level: MPEG-2 SD MP@ML
MPEG-4 AVC SD MP@ML
AVS
Resolution&Frame Rate: PAL: 576I@25fps
NTSC:480I@30fps
Aspect Ratio: 4:3 or 16:9
Audio Decoding
Format: MPEG-1 Layer II,MPEG-2
Operation Mode: Stereo or Mono
Sample Rate: 32khz,44.1khz,48khz
Audio Bitrate:192-384kbps
Analog Video and Audio Output
Composite Video: 8x CVBS,BNC Female 75Ω
Unbalanced Audio:8x Stereo Pairs(R/L),BNC Female
600Ω
Operation Modes: Stereo or Mono mode
Analog Balanced Audio(option)
Numbers of interface: 8x Stereo pairs(R&L)
Connector Type: XLR male,110Ω
Operation Modes: Stereo or Mono mode
Remarks: This hardard option is available for 2RU
System function
100M Base-T Ethernet, RJ45,WEB((IE 8.0 or above)
6 keys: UP, DOWN, LEFT, RIGHT, ENTER,ESC
Front-Panel LCD configuration, LED indicate light
Environment
Power Supply:AC 110-240V  50/60Hz
Power consumption: 30W
temperature:0~45℃(Operation), -20~80℃(Storage)
Dimensions: L: 450mm, W: 483mm, H: 44.5mm(1RU)
Weight: 3Kg
