Advanced H.265 HEVC Transcoder
Overview
Anystreamer340 is targeted to next-generation HDTV displays and content capture systems that feature progressive scanned frames and display resolutions from QVGA (320x240) up to 1080p and Ultra HDTV 2160p (3840x2160.) HEVC’s flexible Coding Units, which can be up to 64x64, replace fixed-sized H.264 macroblocks, sub-partitioning the picture into rectangular regions. In addition, the intra-picture or inter-picture prediction types provide higher encoding flexibility. The result is a codec that can offer up to 50% reduced bitrate at the same quality when compared to AVC/H.264.
Anystreamer340 features outstanding picture quality in an all-IP environment with live broadcast-quality encoding, innovative video preprocessing, and faster-than-real-time file transcoding.In addition to the added support for the HEVC video codec, supports all major industry codecs and formats including MPEG transport streams, Adobe® Flash®, Apple® HTTP Live Streaming, Microsoft® Smooth Streaming,Wowza Server and EZserver for Web TV, over-the-top (OTT) services, IPTV, and cable delivery.
Key Features
l Using standard 1RU chassis, core with the FPGA matrix, CPU, GPU as the parallel processing technique assisted collaborative.
l Best-in-class video quality.
l Support 1channels Ultra-HD and Full HD or 4 channels SD or user-defined type real-time transcoding
l Support selectable any one of SDI,AVHDMI,HD-SDI input
l Support MP2, MP3, AAC, AC3 and other audio codec standards
l Supports multiple video/audio codecs, including HEVC
l Video codec rate 50k-5Mbps,audio rate 8k-384kbps
l Ultra-HD(4K)Option, Full HD (1920*1080p), high definition (1280*720p), standard definition (720*576, 720*480),CIF,QCIF or a custom video transcoding resolution.
l Optimized for 350 Kbps for 480i/576i, 1 Mbps for HD 720p, 1.5 Mbps for HD 1080i and 2.5 Mbps for HD 1080p in HEVC encoding
l Support CAVLC,CABAC entropy coding mode selection, motion estimation search range setting and de-interlacing algorithm selection.
l Support CBR, VBR rate control mode.
l Support same input source mapping multi-resolution, bitrate, Codec, protocol, interface output.
l Dual Gigabit Ethernet LAN ports provide additional performance and redundancy. Seperate ethernet ports for service streaming and out-of-band management
Application
IPTV, Mobile TV multi frequency application,
Broadcast and cable TV system,
Content storage and video server system,
Intelligent security monitoring system,
News gathering, return code,
Signal stream and stream compression, which can meet the broadcast, VOD, enterprise, education, medical treatment, health center and live broadcast market demand.
Technical specifications
2) 3-year warranty
3) Perfect after-sale service and technical support
