Real Time Stream processor and HD/SD Transcoder
ENC3580 is a professional bidirectional transcoder to convert video between H.264 and MPEG-2 format and also to transcode between HD and SD programs simultaneously. It is equipped with 6 DVB-S2/C/T tuner inputs to receive channels directly, or ASI /IP inputs to receive digital channels. After transcoding, it outputs MPTS & SPTS through the DATA IP or ASI port.
One of the main features of ENC3580 is integrated HD-to-SD down Converting,making the launch of differentiated services, such as an all-HD broadcast of the SD lineup simple and cost effective.
Another outstanding feature of ENC3580 is that it can transcode HD/SD H.264 to MPEG-2,so that easy to change H.264 signals from satellite and so on to low-cost MPEG-2 application system.
BISS function is now embedded to descramble your tuner input programs and CC function as well to transport your closed caption (or teletext).It can be easily managed through web NMS system, and has become an ideal solution for operator to provide high quality video trans-coding.
- High-quality,high density transcoding of 8 SD or 4 HD mpeg-2 and MPEG-4 AVC broadcast channels
- SD/HD MPEG-2 to MPEG-2 and MPEG-4 AVC to MPEG-4 AVC re-encoding
- HD to SD down conversion
- 8 * IP (SPTS/MPTS) input plus 6 tuners or ASI inputs
- 8*SPTS & 1*MPTS (UDP/RTP/RTSP) output;2 indentical ASI output
- MPEG-2 SD/HD and H.264 SD/HD any-to-any Video Transcoding
- AAC and MPEG-2 any-to-any audio trans- coding or pass-through; AC3 pass through
- 1920x1080I, 1280x720P, 720x576i, 720x480i, 480x576, 544x576, 640x576 and 704x576 resolutions
- Supporting CBR and VBR rate control
- Advanced re-multiplexing
- Easy-to-Use System Management
- LCD & Key board local control; web NMS management
Stream In |
MPTS/SPTS over UDP/RTP, 1000M Base-T Ethernet Interface/ SFP interface |
|||
6 * DVB-S2 Tuner (DVB-C/T/ISDB-T/ATSC Optional) | ||||
6*ASI | ||||
Video |
Resolution |
1920x1080I,1280x720P, 720x576i, 720x480i 480x576, 544x576, 640x576, 704x576 |
||
Trans-coding |
4*MPEG2 HD → 4*MPEG2/H.264 HD ; 4*MPEG2 HD → 4*MPEG2/H.264 SD ; 8 *MPEG2 SD → 8 *MPEG2/H.264 SD |
|||
|
4* H.264 HD → 4*MPEG2/H.264 HD ; 4* H.264 HD → 4*MPEG2/H.264 SD ; 8* H.264 SD → 8 *MPEG2/H.264 SD | ||||
Rate Control |
Stream In: |
VBR(H.264 SD/HD); CBR(MPEG-2 SD/HD) |
||
Stream Out: |
CBR |
|||
Audio |
Transcoding |
MPEG2, MPEG2-AAC, MPEG4-AAC any-to-any; AC3 pass through |
||
Sampling rate |
48KHz |
|||
Bit Rate |
64Kbps-384Kbps |
|||
Stream Out |
8*SPTS & 1*MPTS over UDP/RTP/RTSP, 1000M Base-T Ethernet Interface(UDP/RTP uni-cast/multicast) /SFP interface |
|||
2*ASI (as a copy of one of the 8 SPTS or the MPTS) output, BNC interface | ||||
Management |
LCD & Key board control; web NMS management,Ethernet software upgrade |
|||
Back Panel: | ||||
Environment |
Dimensions |
430mm×405mm×45mm(WxDxH) |
||
Weight |
6 Kg |
|||
Temperature range |
0~45°C(Operation), -20~80°C(Storage) |
|||
Power Supply |
AC 110V±10%, 50/60Hz or AC 220V±10%,50/60Hz |
|||
Power consumption |
20W |
|||
1) High quality and low price
2) 3-year warranty
3) Perfect after-sale service and technical support
