16Channel RCA H.264/MPEG4 AVC Video Encoder and Converter av to ip tv

 Telco,Broadcast multiscreen 16 RCA/IP H.264 Encoder

Overview

  Caster-T300T high-performance standard definition solution allows content owners and service providers

to significantly increase the content hours delivered while adhering to processing timetables and video

quality targets in a cost-effective and scalable manner.a real-time multi-channel,codec,format IP-based

encoder for multi- screen delivery(TV, Mobile, and Web). With the support for various encapsulation formats

base on embedded Linux operating system appliances. It relies on an Intel 4 or more Core CPU as an accelerator.

 Caster-T300T can push /pull an MPEG-2,H.264,MPEG-4 encoding video streams deliver to various servers,

such as Adobe Flash Server, Wowza Server, Windows Media Server, Apples HTTP Live Streaming, and some other

servers base on UDP/RTSP/RTMP/HTTP/RTP protocols.

Key Features

• Up to 16 Composite,R/L analog audio,Configurable for 16 channel out.
• Optimized for 500 Kbps for 480i/576i, 1.5 Mbps for HD 720p, 2.5 Mbps for HD 1080i and 3.5 Mbps  for HD 1080p.
• Multiple output streams per input service to support Broadcast,VOD,IPTV and OTT,mobile/ web,    Set top box applications
• SD MPEG4/H.264/MPEG-2 to any resolution encoding,Optional Upscale conversion
• Mulltiple Codec,Protocol,Bitrate,Resolution, Profile per channel
• GbE IP outputs – UDP,RTSP,RTMP,HTTP,HTTP Live Smooth(HLS),FTP M3u8 playlist files
• Audio support: AAC,MPEG,MP3 or Dolby Digital AC-3 passthrough
• High quality pre-processing including filtering,Deinterlacing,cross scaling,image insertion
• Based on embedded unbuntu Linux
• Superior video quality at ultra-low bitrates, generally video advised SD about 500kbps for lowest bitrate
• Selectable any resolution from QSIF to 576p
• Easy-to-Use System Management
• Web Management
