Insulated Factory Price Frp Rod, Isolated Solid Fiberglass Smooth Rod

Name: Insulated Factory Price Frp Rod, Isolated Solid Fiberglass Smooth Rod
Brand: Juli
SKU: 110653517

US$ 0.1 - 10 MOQ: 500 Meters

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

Juli

Model Number:

JFP060

Dongguan Juli Frp Products Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Yantian Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name Juli

Model Number JFP060

Application water/oil transport,construction

Surface Treatment Smooth.matted/anti-slip

Technique Pultrusion

Dimensions various, 2mm to 50mm and according to you requirement

Insulated Factory Price Frp Rod, Isolated solid Fiberglass smooth Rod

Product Description

Solid fiberglass rods
1.ISO9001 Certificate
2.High strength
3.Light weight,Insulation
4.Excellent corrosion resistance

1-The Process About Fiberglass Pultrusion :

Production process is a continuous production process to produce fiber-reinforced polymer profiles of any length

and constant section. Reinforcement fibers may be roving, continuous mat, woven roving, carbon or others. The

fibers are impregnated with a polymer matrix (resin, minerals, pigments, additives) and passed through a pre-forming

station that produces the stratification necessary to give the profile the desired properties. After the pre-forming step,

the resin-impregnated fibers are pulled through a heated die to polymerize the resin.

'fiberglass flat rod,flexible fiberglass rod,5mm fiberglass rod'

We Can Supply Strong FRP Pultrusion fiberglass rods and tubes

2 -Fiberglass Profile Properties

Technical Data of Duct Rodders

1. Glass Reinforced Composite core:
General properties
Property	Value
Keinforcement	E-Glass Fiber
Glass Content of Inner Part	75-80%
Material of Pulling Rod	Epoxy fiber glass (inner) High density Polyethylene(outer)
Density	> 1.9 gr/cm3
Diameter Tolerance	± 0.10mm
Work situation temperature	- 400 º C to +800 º C
Mechanical properties
Property	Value
Minimum pulling strength	4000 N± 5%
Tensile Modulus	> 30000 Mpa
Consistency of rod	150gr/m± 5%
Flexural Modulus	> 30000 Mpa
Elongation at Break	2.5-3%
2. Polyethylene cover
Material: Medium Density Polyethylene Resin for the insulating and jacketing of Telecommunication Cables.
Property	Value
Tensile Strength	> 15N/mm2
Environmental Stress & crack resistance	> 1000 hr.
Heat Stability	OK.
Carbon Black	OK.
