High Performance H.264 Iptv Encoder With Http/udp/rtmp/rtsp/hls Protocols

High Performance H.264 Iptv Encoder With Http/udp/rtmp/rtsp/hls Protocols thumbnail-1
High Performance H.264 Iptv Encoder With Http/udp/rtmp/rtsp/hls Protocols thumbnail-2
High Performance H.264 Iptv Encoder With Http/udp/rtmp/rtsp/hls Protocols thumbnail-3
High Performance H.264 Iptv Encoder With Http/udp/rtmp/rtsp/hls Protocols photo-1
High Performance H.264 Iptv Encoder With Http/udp/rtmp/rtsp/hls Protocols photo-2
High Performance H.264 Iptv Encoder With Http/udp/rtmp/rtsp/hls Protocols photo-3
US$ 1,000 - 7,500 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
Dibsys
Model Number:
Caster-T300H
Contact Supplier Request Quote Chat Now
Hangzhou DIBSYS Technologies Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai/Hangzhou
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name Dibsys
Model Number Caster-T300H
Product Description

Caster-T300H high-performance standard definition solution allows content owners and service providers to significantly increase the content hours delivered while adhering to processing timetables and video quality targets in a cost-effective and scalable manner.a real-time multi-channel,codec,format IP-based encoder for multi- screen delivery(TV, Mobile, and Web). With the support for various encapsulation formats base on embedded Linux operating system appliances. It relies on an Intel 16 or more Core CPU as an accelerator.

Caster-T300H can push /pull an MPEG-2,H.264, MPEG-4 encoding video streams deliver to various servers, such as Adobe Flash Server, Wowza Server, Windows Media Server, Apples HTTP Live Streaming, and some other servers base on UDP/RTSP/RTMP/ HTTP/RTP protocols.

Feature

1.Up to 12/18/24 Composite,R/L analog audio per chassis

2.Optimized for 500 Kbps for 480i/576i, 1.5 Mbps for HD 720p, 2.5 Mbps for HD 1080i and 3.5 Mbps for HD 1080p.

3.Multiple output streams per input service to support Broadcast,VOD,IPTV and OTT,mobile/ web,Set top box applications

4.SD MPEG4/H.264/MPEG-2 to any resolution encoding

5.Mulltiple Codec,Protocol,Bitrate,Resolution, Profile per channel

6.GbE IP outputs – UDP,RTSP,RTMP,HTTP,HTTP Live Smooth(HLS),FTP

7.M3u8 playlist files

8.Audio support: AAC,MPEG,MP3 or Dolby Digital AC-3 passthrough

9.High quality pre-processing including filtering,Deinterlacing,cross scaling,image insertion

10.Based on embedded unbuntu Linux

11.Superior video quality at ultra-low bitrates, generally video advised SD about 500kbps for lowest bitrate

12.Selectable any resolution from QSIF to 576p

13.Easy-to-Use System Management

14.Web Management

INPUTS
Baseband input
 12x Composite,R/L analog audio
18x Composite,R/L analog audio
24xComposite,R/L analog audio
OUTPUTS
IP Output type
Two Gig Ethernet Ports
ASI output type
Mutliplexed (optional)
Streaming format
Mpeg-2/H.264/H.263/MPEG4 SP/MPEG4 ASP;
MPEG-1 Layer II,AAC,AC3,AMR,WM A ,MP3
TS  Over UDP/RTP/HTTP
3GP Over RTP
FLV Over HTTP/RTMP
HTTP Live streaming
Apple HLS (m3u8)
File Output
Encoding
3GPP/3GPP2/WMV/FLV/TS
File output support timing and capacitive record
Pre-processing
Image setting
Video adjustments（Brightness, contrast, Saturation, Hue）
Frame rate
from 2fps to 30fps
Aspect ratio
4:3 and 16:9, WSS control
Image insertion
LOGO insertion
Subtitle Overlay
Static or roll subtitle, up to 3 way (optional)
PID Configuration
Depending on the configuration, it forwards selected programs via IP data casting; PAT, PMT, video PID, audio PID(s) and PCR information are transmitted.
Video encoding
Bitrate mode
VBR,CBR
Resolutions
80x64 • 176x120 • 128x96 (4:3) • 176x128 • 144x80 • 176x144 144x140 • 220x176 • 160x90 (16:9) • 240x176 • 320x240
352x288 • 400x300 • 480x360 • 720x576 • 854x480(16:9)
Max channels per RU
Singal Input
H.264 Out
Channels
Notes
CVBS
SD in 1.5Mbps
12 streams
Take those information as reference only,For details contact us
Up to 96 streams
Up to 24 streams
Up to multiple concurrent outputs per one stream input
Video codec
H.263 Profile0, Levels 10,20,30
MPEG-4 SP, Levels 0,0b, 1,2,3
H.264 Baseline Levels 1,1b,2,3;
H.264 Main Profile/High Profile 3.0- 5.1
MPEG-2 MP@ML 4:2:0
GOP Size
I-Frame Time Interval; B-Frame Number; Reference Frame
Video Bitrate
32kbps to 4Mbps
Enhancement filter
Deinterlacing; MABFF CABAC; Noise reduction; Sharpening; Visual Optimizing
Audio encoding
Audio encoding
LC-AAC,HE-AAC and HE-AACv2 (including Parametric Stereo)
MPEG-1 Layer, AC3,MP3
Sample rate
8khz to 48khz
Data rate
8kbps to 384kbps
Management
Interfaces
LCD display, key button, WEB
Environment
Power Supply
110-240 VAC
Power consumption
50W
Operation temperature
0 -50°C (32 -122°F)
Storage temperature
-40-70°C (-40-158°F)
Dimensions
483mm (W) x 534mm (L) x 45mm (H)
Weight
11kg(24lbs)
Multiscreen SD Encoder
Caster-T305
Up to 4 SDI inputs
Caster-T305H
Up to 8 SDI inputs
Multiscreen HD Encoder
Caster-T310
Up to 1,2,4x HDMI inputs
Caster-T310H
Up to 8x HDMI inputs
Caster-T315
Up to 1,2,4x HD-SDI inputs
Multiscreen Transcoder
Caster-T320D
Two ports GigE IP in/ out: up to 8x SD ,10x SD, 12x SD streams out
Caster-T322
Two ports GigE IP in/ out: up to 20x SD streams out
Caster-T324
Two ports GigE IP in/ out: up to 60x SD streams out
