Help CenterSMD Mini LED Panel
Related Products
Specifications
Mini LED Panel :1. CE ROHS 300*300 led panel
2. AC100-120V/AC220-240V white light
3. Epistar SMD 3528
4. 300*300 SMD
White SMD Mini LED Panel
Specifications:
Net Weight 1.5kg
Light Color white, warm white, cold white
Illumination Range 5m
Input Power 19W
Water Proof IP50
Luminous flux 1000lm
Size 300*300*13.5mm
LED Quantity 180pcs
LED Type SMD3528
Beam Width 160°
Input Voltage AC100-120V/AC220-240V
Material aluminum alloy, PMMA optical light guide plate .
Ambient Temperature -20°C ~ +45°C
Luminous Efficiency 57.66lm/W
LED Panel Light FEATURES :
1. LED panel is a kind of advanced indoor light, which inherits the characteristics of simplicity and classics of Europe style. It is gaining the favor of customers for its super thin profile and clear bright light effect. LED panel creates a strong sense of depth and space when applied in indoor places such as meeting room, VIP reception room, and hotel.
2.The frame is made of 6063 aluminum alloy with anodic oxidation treatment, which is very good in heat dissipation. Light source is 3528 LED, which can create a flat lighting effect when its light pass through the light guide plate.
3. LED panel is more energy saving and environment protecting with longer life than traditional light products. Its light is well-proportioned, soft, comfortable and bright.
LED Panel Light Installation:
Method 1: Secure the ropes to the mounting holes, hang the LED panel from the ceiling.
Method 2: Drive nails in the wall and hang the panel on the nails.
LED Panel Light Notes:
1. Please read instructions carefully before start installation;
2. Input voltage shall comply with the instruction;
3. Recommended ambient temperature is from -20C to +45C, use the product beyond the temperature range will bring bad effect to its service life.
4. This product is for indoor use only;
5. Installation and maintenance of the product should be carried our by professional person.
Remarks: Design and specifications subject to change without notice.
