Specifications
EFR 150w co2 laser tube1.lifespan:6000 hours
2.warranty period:180 days
3.Catalyst:yes
4.length:1850mm
EFR 150w co2 laser tube
Our co2 laser tubes have the advantages of high quality. It is mainly used for cutting, sculpturing. It could be used in laser mould manufacturing too.
F series co2 laser tube-----Features
1.Stability: the discharge glass tube body is imported from Germany. The laser beam mode is
up to TEM00. The power is table. It is competitive for industrial application.
2. Power: The power is 30% higher than other laser tube with same length.
3. Long Life: the catalyst coating on discharge tube with unique electrode processing makes the laser out put is more stable, avoid power weaken during long time working.
Products Parameters Lists for F series
Model |
Length (mm) |
Diameter (mm) |
Rated Power (W) |
Max Power (W) |
Current (mA) |
Catalyst |
F2 |
1250 |
Ø80 |
80 |
95 |
28 |
YES |
F4 |
1450 |
Ø80 |
100 |
120 |
30 |
|
F6 |
1650 |
Ø80 |
130 |
150 |
30 |
|
F8 |
1850 |
Ø80 |
150 |
180 |
30 |
|
F10 |
2050 |
Ø80 |
180 |
200 |
30 |
Quality Promise
Working Life: up to 6000 Hours
Warranty: 180 Days
