Help Center1600mm Co2 Laser Tubes
Related Products
Specifications
Good mode, small beam spot
CL serial CO2 laser tube’s characteristics
1. CL serial CO2 laser tubes can stably give out laser beam. By means of special equipment and import gas ,the decomposition speed of the working gas has been effectively reduced so as to greatly prolong its working lifespan .These advantages of our products make our customers experience the features of EFR products’ high performance-to-price ratio.
2. Good mode (base film more than 95%) and small beam spot (3-5mm).
3. High-power ,such as the power of 1200mm CO2 tubes usually reaches more than 70W,1600mm CO2 laser tubes’ power can reach more than up to 100W.
4. Applied to laser engraving, laser cutting, laser carving, laser drilling, etc. A complete range of specifications can be widely used in industrial cutting ,laser engraving, laser mould processing, laser engraving machine , laser cutting machine , laser marking machine, crafts engraving, leather processing ,decoration and laser medical treatment machine and lots of other fields.
Detailed Product Description:
CO2 glass laser tube Model pl-1600, 1600mm long, diameter 60mm, output power 80 watt.
Parameters list for CO2 Laser tubes of CL, PL Series
Model |
Length (mm) |
Diameter (mm) |
Output Power (w) |
Maximum Power (w) |
Operating Current (m A) |
Output Laser Mode |
PL-1600 |
1600± 2 |
¢60± 2 |
80± 5 |
90 |
25 |
Lower mode |
CL-1250 |
1250± 2 |
¢55± 2 |
65± 5 |
70 |
22 |
|
CL-1200 |
1200± 2 |
¢55± 2 |
60± 5 |
70 |
22 |
Quality Assurance ( cl series)
Lifespan: 3000 hours
Warranty period: 4 months
