Home > Products > LED Modules > SMD5050 IC LED Module Diffusing Waterproof
SMD5050 IC LED Module Diffusing Waterproof
- 50000 Piece / Pieces per Month
- Shenzhen
- Credit Card
Product Details
Model Number: | BG-0209-5050-IC | Chip Material: | GaP | Power: | Other, 1.5W/pc |
Operating Temperature(℃): | -25, 60 | Storage Temperature(℃): | -40, 80 | Place of Origin: | Guangdong, China |
Brand Name: | BRIGHT | Certification: | CE |
Product Description
Specifications
Color changing modes like water-flowing,chasing, gradually changing,flashing,diffusing and other kinds of colorful performanceFEATURES:
l LED quantity: 4pcs SMD5050 for each unit.
l Waterproof material: epoxy resin
l Size: 35*35*4mm
l Working condition: 12v DC,
l Power: 1.5W per pcs
l Protection: IP68
l Color changing modes like water-flowing, chasing, gradually changing, flashing, diffusing and other kinds
of colorful performance.
l If large quantity LED module connect with controller can be worked like the LED panels. The program you
can change by yourself.
l Application: advertising signs, indoor decoration and other kinds of edge lighting
Connector with controller
Connection diagram
APPLICATION CONNECTION 1
DMX512 signal ( light effects can be edit by a software on PC )
APPLICATION CONNECTION 2
Digrtal Controller
APPLICATION CONNECTION 3
Digrtal Controller with SD CARD
Application:
Widely used in Advertising board,letters,lightbox,Marks,Direction,
Indoor Decoration,Cabinet light,Out wall decoration,and Lighting Project….etc
