1X2 1X4 1X8 1X16 1X32 1X64 1X128 ABS Box PLC Splitter

Name: 1X2 1X4 1X8 1X16 1X32 1X64 1X128 ABS Box PLC Splitter
Brand: FH-NET
SKU: 110626407

US$ 1.00 - 1.00 MOQ: 100 Pieces

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

FH-NET

Model Number:

Splitter

Shenzhen FH-Net Optoelectronics Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name FH-NET

Model Number Splitter

Specifications

1×N PLC Splitter

(Measured at room temperature and excludes connector loss)

Type		1×2	1×4	1×8	1×16	1×32
Fiber Type		9/125 um SMF-28e or custom on request
Operating Wavelength (nm)		1260~1650
Insertion Loss (dB)	Typical	3.6	6.8	10.0	13.0	16.0
Insertion Loss (dB)	(P/S) Max	3.8/4.0	7.1/7.3	10.2/10.5	13.5/13.7	16.5/16.8
Loss Uniformity (dB)	Max	0.6	0.6	0.8	1.2	1.5
Polarization Dependent Loss (dB)	Max	0.15	0.15	0.25	0.3	0.3
Directivity (dB)	Min	55
Return Loss (dB)	Min	UPC:50 APC:55
Operating Temperature(℃)		-40~85
Storage Temperature(℃)		-40~85

2×N PLC Splitter

(Measured at room temperature and excludes connector loss)

Type		2×2	2×4	2×8	2×16	2×32	2×64
Fiber Type		9/125 um SMF-28e or custom on request
Operating Wavelength (nm)		1260~1650
Insertion Loss (dB)	Typical	4.0	7.0	10.5	13.5	16.5	20.5
Insertion Loss (dB)	(P/S) Max	4.1/4.3	7.4/7.6	10.8/11.0	14.3/14.5	17.3/17.5	20.7/21.5
Loss Uniformity (dB)	Max	0.8	0.8	1.5	2.0	2.5	2.5
Polarization Dependent Loss (dB)	Max	0.2	0.2	0.3	0.4	0.4	0.4
Directivity (dB)	Min	55
Return Loss (dB)	Min	UPC:50 APC:55
Operating Temperature(℃)		-40~85
Storage Temperature(℃)		-40~85
