Best seller 10G SFP+ module price from China manufactury
PRODUCT FEATURES
l 10Gb/s serial optical interface compliant to 802.3ae 10GBASE-LR.
l 1310nm DFB transmitter, PIN photo-detector
l Up to 10km transmission on SMF
l Duplex LC connector
l Metal enclosure, for lower EMI
l Electrical interface compliant to SFF-8431
l Specifications for 10 Gigabit “SFP+”
l 2-wire interface for management
l Specifications compliant with SFF 8472
l Single 3.3V power supply
l Power dissipation < 1.5W
l Case operating temperature range: -5°C to 70°C
APPLICATIONS
l 10GBASE-LR/LW 10G Ethernet
STANDARD
l Compliant with SFF-8472 SFP+ MSA.
l Compliant to SFP+ SFF-8431 and SFF-8432.
l Compliant to 802.3ae 10GBASE-LR.
l RoHS Compliant.
Absolute Maximum Ratings
Parameter |
Symbol |
Min |
Typ |
Max |
Unit |
Ref. |
Maximum Supply Voltage |
Vcc |
-0.5 |
|
4.7 |
V |
|
Storage Temperature |
TS |
-40 |
|
85 |
°C |
|
Case Operating Temperature |
Tcase |
-5 |
|
70 |
°C |
|
Electrical Characteristics (Tcase = -5 to 70℃, VCC = 3.14 to 3.46 Volts)
Parameter |
Symbol |
Min |
Typ |
Max |
Unit |
Ref. |
Supply Voltage |
Vcc |
3.14 |
3.3 |
3.46 |
V |
|
Supply Current |
Icc |
|
|
300 |
mA |
|
Transmitter |
|
|
|
|
|
|
Input differential impedance |
Rin |
|
100 |
|
Ω |
1 |
Single ended data input swing |
Vin,pp |
180 |
|
700 |
mV |
|
Transmit Disable Voltage |
VD |
Vcc–1.3 |
|
Vcc |
V |
|
Transmit Enable Voltage |
VEN |
Vee |
|
Vee+ 0.8 |
V |
2 |
Transmit Disable Assert Time |
|
|
|
10 |
us |
|
Receiver |
|
|
|
|
|
|
Differential data output swing |
Vout,pp |
300 |
|
850 |
mV |
3 |
Data output rise time |
tr |
28 |
|
|
ps |
4 |
Data output fall time |
tf |
28 |
|
|
ps |
4 |
LOS Fault |
VLOS fault |
Vcc–1.3 |
|
VccHOST |
V |
5 |
LOS Normal |
VLOS norm |
Vee |
|
Vee+0.8 |
V |
5 |
Power Supply Rejection |
PSR |
100 |
|
|
mVpp |
6 |
Service
1. Competitive selling price
2. Warranty: 1-3 years warranty
3. Excellent after-sale service
4. Samples are available for testing
5. Reply your inquiry within 2 hours
6. You can get our support online at 24*7
7. Big capability of manufacture and fast delivery time
8. With experienced technical team supporting
9. Customized label and package, ODM and OEM service offered
10. 100% new materials for production and 100% reliable quality
