SMD5050 LED Modules,CE RoHs SMD 3 led module
SPECCIFICATION:
1. Injection Module adopts ABS material as its shell. There is transparent epoxy resin around the lights with good insulativity.
2. Comprehensive performance is good with excellent electrical performance, impact strength and wear resistance, chemical resistance, moisturecontent , shaping and excellent machining technology.
3. It is completed through injection in one time. It solves the problem that nonuniform sealing, dirty shell and LED stand out of the glue etc. It is simple artwork with good appearance and short lead time as well.
4. It has good cold resistant available for -20~40°C. There are 3M adhesivetape and screws for customers to fix it in easy installation.
5. It is widely used for emitting letters, advertisement, indoor decoration ,partial lighting, etc
| Item | SMD5630 LED Light bar |
| Light source | SMD5630 |
| Power | 0.9W |
| Voltage | DC12V |
| LED Qty. | 2 pcs |
| Lumen flux | 90Lm |
| PF | 0.92 |
| Color | Single Color and RGB |
| Working tempratures | -20 - +40 |
| IP Grade | IP65 |
| Certificator | CE ROHS |
| Size | 48*16*5.8mm |
| Body | Aluminum Alloy |
| CCT. | 2700-10000K |
FEATURES:
1.LED QTY.:2* SMD5630 led/pcs
2.LED Color:Single color
3.Voltage:DC12V
4.Max Power:0.9W/pc
5.Beam angle:120°
6.Waterproof:IP65
7.Stucture:sing Silica gel wire.Injection Tooling with high productivity, The plastic housing with perfect Anti-aging ability
Application
1) Channel Letter lighting
2) Advertisement broad Backlighting;
3) Advertisement signs Backlighting;
4) Advertisement Light Boxes Backlighting
5) Indoor Decoration,Cabinet light.
6) Out wall decoration,and Lighting Project….etc
Warning:
1.Please do not connect power supply when the light is still in box.
2.Please do not connect high voltage before the installation, and make sure that the fixture connect
the earth.
3.Change the protection cover completely if it was broken.
4.Pay attention to anti-fire, anti-electricity and anti-shake.
5.Caustic or dissolvent chemicals may damage the protection crust.
6.Normal working temperature : -35°C-40°C, if overrun the range, it will effect the lifespan of lamp. Storage temperature is -25~60°C
