SMD LED RGB Module IP 65

Name: SMD LED RGB Module IP 65
Brand: Bright
SKU: 110623183
Availability: InStock

US$ 0.1 - 0.8 MOQ: 500 Pieces

Key Specifications

Model Number:

LED Module Light

Chip Material:

InGaN

Luminous Flux(lm):

Shenzhen Bright Technology Industrial Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen China

Delivery Detail:

Delivery time depends on order quantity.

Model Number LED Module Light

Chip Material InGaN

Luminous Flux(lm) 68

Optical Attenuation(%) 0.3

Color Rendering Index(Ra) 80

Color Temperature 3000K

Operating Temperature(℃) -20, 60

Place of Origin Guangdong, China

Brand Name Bright

Certification CE

Specifications

LED RGB Module
Light Source: SMD3528/5050 LED
Epistar led chip
CE, RoHS
120 beam angle

LED Module Light

Part No.	Picture	LED Qty.	LED TYP.	Voltage	Power	Lumens	Beam Angle	IP	Size:	Color
BG-0201-2-2607		2pcs	SMD 3528	12V DC	0.16W	11-13 Lm	120°	IP65	26*7 mm	White Warm white Red Green Blue Yellow
BG-0201-2-3912		2pcs	SMD 3528	12V DC	0.16W	11-13 Lm	120°	IP65	39*12 mm	White Warm white Red Green Blue Yellow
BG-0201-3-3912		3pcs	SMD 3528	12V DC	0.24W	18-20 Lm	120°	IP65	39*12 mm	White Warm white Red Green Blue Yellow
BG-0201-3-4512		3pcs	SMD 3528	12V DC	0.24W	18-20 Lm	120°	IP65	45*12 mm	White Warm white Red Green Blue Yellow
BG-0201-3-7512		3pcs	SMD 3528	12V DC	0.24W	18-20 Lm	120°	IP65	45*12 mm	White Warm white Red Green Blue Yellow
BG-0201-3-7512A		3pcs	SMD 3528	12V DC	0.24W	18-20 Lm	120°	IP65	45*12 mm	White Warm white Red Green Blue Yellow
BG-0201-4-3535		3pcs	SMD 3528	12V DC	3.0W	23-26 Lm	120°	IP65	35*35 mm	White Warm white Red Green Blue Yellow
BG-0202-1-2012		1pcs	SMD 5050	12V DC	0.2 W	14-16 Lm	120°	IP65	20*12 mm	White Warm white Red Green Blue Yellow R G B
BG-0202-2-4512		2pcs	SMD 5050	12V DC	0.36 W	28-30 Lm	120°	IP65	45*12 mm	White Warm white Red Green Blue Yellow R G B
BG-0202-3-4512		3pcs	SMD 5050	12V DC	0.55 W	46-51 Lm	120°	IP65	45*12 mm	White Warm white Red Green Blue Yellow R G B
BG-0202-3-7512		3pcs	SMD 5050	12V DC	0.55 W	46-51 Lm	120°	IP65	75*12 mm	White Warm white Red Green Blue Yellow R G B
BG-0207-3-5050		3pcs	SMD 5050	12V DC	0.55 W	46-51 Lm	120°	IP65	35*35 mm	White Warm white Red Green Blue Yellow R G B
BG-0207-4-5050		3pcs	SMD 5050	12V DC	0.75 W	61-68 Lm	120°	IP65	35*35 mm	White Warm white Red Green Blue Yellow R G B
