Specifications
30-250W LED Industrial LightHigh-purity reflector lighting
High power LED 30-250W
Long life span LED>50000 hours
CE & RoHS
30-250W LED Industrial Light,
30-250W LED Industrial Light Features:
- Use single powerful LED(30W–100W)as the light source , using our proprietary LED encapsulation.
- Utilizes the special design of multichip single module. Imported high brightness semiconductor chips.
- High heat conductivity, low luminous decay, pure light color and no ghosting.
- Integrative design for heat sink and housing; The LED is closely connected to the surface. The heat from the LED is removed through the heat dissipation wing and also by air ventilation. This ensures 50,000 hours life-span for the LED. If it works 11-12 hours per day, it can work over 10 years.
- The surface is passed through anodic oxidation treatment. Its structure is compact and beautiful. It can meet the requirement of IP65. It has good capacity like antisepticising, waterproofing, and dust prevention.
- Obvious power-saving efficiency. Use powerful LED light source and high efficiency imported LED driver. Compare with sodium lights, it can save electricity around 60%.
- Environment friendly. Do not have lead, hydrargyrum and any other contamination. No pollution to the air.
- Can present the original color of the objects, it has varies of colors to choose which can meet the requirements in different environments. It eliminates the dullness of environments caused by the lower color temperature, like sodium lamp, or higher color temperature, like mercury lamp. This could satisfy the feeling of those who appreciate the lighting.
- The industrial light is controlled by constant current and constant voltage. Its working voltage (AC85V-265V) can overcome the electrical grid, noise pollution and unstable light caused by ballast. It can also eliminate the glare and fatigue.
- Can be a good decoration light. Its surface is specially treated. The housing can be with different kinds of colors.
- Easier to be installed and to be unloaded; Can be used in different places
30W LED Industrial Light Lighting Technical Parameter
Input Voltage | AC85V~265V | ||
Freqency Range | 50Hz~60Hz | ||
Total Harmonic Distortion | ≤ 9 % | ||
Power Factor | >0.9 | ||
Power Efficiency | >83 % | ||
Working Voltage | DC30~36V | ||
LED Quantity | 1 pc | ||
LED Consumption | 30 W | ||
System Consumption | 36 W | ||
LED Luminous Efficiency | 70 Lm /W | ||
LED Initial Flux | 1692 Lm | ||
Lamp’s Efficiency | >91 % | ||
Average Illuminance | 6 | 75.671 LUX | |
8 | 42.56 LUX | ||
10 | 27.24 LUX | ||
Illuminance Area | 6 | Cycloidal Area Dia Is 32 M | |
8 | Cycloidal Area Dia Is 43 M | ||
10 | Cycloidal Area Dia Is 53.3 M | ||
Illuminance Uniformity | >0.5 | ||
Color Temperature | (See the LED Parameter table) | ||
Color Rendering Index | Ra>75 | ||
Light Distribution | Symmetertric/Round Spot | ||
Light Design | LED+Second with light reflectors | ||
Junction Temperature | ≤80°C | ||
Working Temperature | -40°C ~ +55°C | ||
Storage Temperature | -25°C ~ +65°C | ||
IP Grade | IP65 | ||
Net weight | 3.2 Kg | ||
Working Life-span | 50000H | ||
Power line | 0.75mm2 wire | ||
Connect wire | Brown | L | |
Blue | N | ||
Yellow/Green | G | ||
(The color of the lamp shell ) | Black,argentate | ||
Certificate | CE | ||
30
