automatic sliding door drive from china supplier with best price with key switch dc motor sensor radar
KS series sliding door system is one of KBB best selling products, at least 10,000 units could be installed in the hotels, airports, office buildings, shopping malls in the world every year, they possess leading technologies, multi- functions, dependable performance while being cost efficient.
1. The Radars are all worldwide famous brands, such as BEA from Belgium, OPTEX from Japan, which are more sensitive, make people safe when they go through the door.
2. The safety beam which installed in the fix-door frame, keep people safe from squeezing.
3. UPS backup battery ensures the door operates 30 minutes normally if power fails.
4. Install an electro-mechanical lock to ensure the door be locked more safely.
5. The thickness of supporting rail was 5mm, which is much stronger than the industry average 3 to 4mm .
1. Maximum Door Weight ( Single Parting ) : 1 × 150kg.
2. Maximum Door Weight ( Bi - Parting ) : 2 x 120 kg.
3. Opening Speed Range: 0.4 - 0.7m / s (adjustable).
4. Closing Speed Range: 0.3 - 0.6m / s (adjustable).
5. Keep Opening Time Adjustable Range : 5~10s (5s, Standard) .
6. Power supply: 220VAC±10%,50HZ ,10A .
7. Rated power: 100W .
8. Max. drive power (static): 150N .
9. UPS backup battery: 30min .
10. Ambient temperature: -30.C – 50.C
11. Max. relative humidity: 90% .
12. Protection level: IP23 .
Door width (DW) : 2w+300mm
Opening width (W) : 800-3000mm
Opening height (H) : ≤2600mm
Length of operator : 2500mm - 7000mm
1. Main control unit -Philips –Netherlands
2. Motor - Dunkermotoren – Germany
3. Radar - BEA (Belgium) /OPTEX(Japan)
4. Durable rail - Special nylon, durable, quiet and self-lubricated
5. PSA control Panel - 37 parameters could be set.
6. Supporting rails - High strength, 5mm thickness
As one of the biggest automatic door suppliers in the world, we KBB specialized in automatic door field for more than 20 years ,supplied automatic revolving door, sliding door , sliding door Operator, medical hermetic door, swing door with higher quality and competitive price.
We have 3 plants in China located in Beijing, Shenyang and Ningbo , pocess the biggest prodcution capacity in automatic door field in China .
Up to now, our doors had already got many certificates such as ISO 9001, ISO14001, CE, UL, TGA, GOST, UKAS etc.
We have the most modern workshops for automatic door producing .
We have the biggest automatic door showroom in the world .
We often go to attend the most famous automatic exhibitions in the wolrd, such as FEICON BATIMAT, R+T EXHIBITION etc..
There are lots of automatic door clients from the wolrd visit KBB to communicate the cooperation every year .
20,000 units sliding doors and 2,000 units revolving doors could be provided every year for the airport, hotel, shopping mall, office building projects. The 4 tallest towers in the world including the Khalifa tower in Dubai, The Titanium in Santiago, The global Financial Center tower in Shanghai and The Shard in London installed our doors.
