Home > Products > Sliding Door > label aluminium sliding door automatic doors
label aluminium sliding door automatic doors
- 1000 Unit / Units per Month
- Ningbo
Product Details
Place of Origin: | Beijing, China | Brand Name: | KBB | Model Number: | KS4000 |
Open Style: | Sliding | Position: | Commercial | Surface Finishing: | Finished |
Type: | Sliding Doors | Door Material: | Aluminum Alloy |
Product Description
KBB Automatic telescopic sliding door, tempered glass, CE certificate
Telescopic sliding door is one of KBB best selling sliding doors, which transcends tradition design ideas, break through modern craftsmanship reaching new heights.
1. Multiple functions.
Multiple functionality allows you to choose from manual operation, automatic full open, automatic half open, one way in/out and locked conditions as required.
37 built-in parameters including door opening speed, closing speed, half opening width, open time and lock status can all be adjusted at your convenience to achieve an optimum state.
2. Quality assurance guarantees
All models have undergone over 3,000,000 inspection examinations including high and low temperature tests. Models have been run for 72 hours at 70 degree with out trouble. Low temperature tests prove normal running operation to an impressive -17 degree .
3. Safety
The door leaves will automatically reverse motion when resistance is detected. Optional electronic locking mechanisms protect users’ safety.
4. Intelligence
The unique PSA control board offers quick and easy function adjustment and overhaul. Placed within 50 meters of the main door, it is capable of handling function adjustment, parameter adjustment, function selection and breakdown diagnosis display.
The operator adopts a modularized design extending the automatic doors life-span, allowing for convenient examination, repair and safeguarding.
5. Quietness
Drive unit adopts a quality speed reduction mechanism, KBB's own creation, a special nylon fiber guide rail and a self-lubricating nylon load bearing pulley mechanism. All greatly reducing the automatic doors motion noise and giving users a quieter and more comfortable experience.
Power supply: 220VAC±10%,50HZ ,10A
Rated power:100W
Max. door opening weight:150N
UPS backup battery: 30min
Ambient temperature: -30 ~ 50 degree
Max. relative humidity: 90%
Protection level: IP23
Remarks: Design and specification are subject to change without notice. Products are tailored to meet your requirement.
Name | Model |
Door width (DW) | >2W+300mm |
Opening width(W) | 4000mm |
Opening height(H) | <=2600mm |
Drive width(KW) | 233mm |
Drive height(KH) | 200mm |
Length of operator | 7000mm |
1, Door glass: Laminated glass/Tempered glass
2, PSA control panel
3, Aluminum alloy frame
4, Motor: Dunkermotoren
5, Carriage wheel
6, Supporting rails
7, PHILIPS CPU
8, Radar
9, Safety beam - Option
10, Key switch - Option
11, Back-up battery - Option
12, Double drive unit - Option
13, Electro-mechanical lock - Option
We KBB specialize in automatic door field for more than 20 years ,supplied automatic revolving door, sliding door , sliding door Operator, medical hermetic door, swing door with higher quality and competitive price.
Up to now, our doors had already got many certificates such as ISO 9001, ISO14001, CE, UL, TGA, GOST, UKAS etc.
20,000 units sliding doors and 2,000 units revolving doors could be provided every year for the airport, hotel, shopping mall, office building projects. The 4 tallest towers in the world including the Khalifa tower in Dubai, The Titanium in Santiago, The global Financial Center tower in Shanghai and The Shard in London installed our doors.
