Specifications
automatic sliding doorGermany motor
BEA Radars and photocell
Philips Control Chip
CE UL ISO9001 certificate
KS series sliding doors possess leading technologies, multi- function, dependable performance while being cost efficient. The best selling models called KS1000/3000, consisting of high-tech components, provides our customers with most steady and favorite choice.
Safety Features:
1. Safety beam which installed in the fix-door frame.
2. UPS backup battery ensures the door operates 30 minutes normally if power fails.
3. Install an electro-mechanical lock to ensure the door be locked more safely.
4. Panic breakout: KS3000 could install this function, it could open during emergency time or oversize object. Overlapping position.
Technical Data:
1. Maximum Door Weight ( Single Parting ) : 1 × 150kg.
2. Maximum Door Weight ( Bi - Parting ) : 2 x 120 kg.
3. Opening Speed Range: 0.4 - 0.7m / s (adjustable).
4. Closing Speed Range: 0.3 - 0.6m / s (adjustable).
5. Keep Opening Time Adjustable Range : 5~10s (5s, Standard) .
6. Power supply: 220VAC±10%,50HZ ,10A .
7. Rated power: 100W .
8. Max. drive power (static): 150N .
9. UPS backup battery: 30min .
10. Ambient temperature: -30.C – 50.C
11. Max. relative humidity: 90% .
12. Protection level: IP23 .
Specifications:
Door width (DW) 2w+300mm
Opening width (W) 800 - 3000mm
Opening height (H) ≤2600mm
Length of operator 2500mm - 8000mm
Key Components:
1. Main control unit -Philips –Netherlands
2. Motor - Dunkermotoren – Germany
3. Radar - BEA (Belgium)/OPTEX(Japan)
4. Durable rail - Special nylon, durable, quiet and self-lubricated
5. PSA control Panel - 37 parameters could be set.
6. Supporting rails - High strength, 5mm thickness
7. Carriage wheel
8. Operator Cover - optional
9.Infrared Safety beam - optional
10.Key switch - optional
11. Ups backup battery - optional
12.Electro-mechanical lock - optional.
13. Double drive unit - optional
