Specifications
ATC cnc processing center /AC servo /Vacuum table/Taiwan Syntec controller/5.5kw ATC spindles/3 axes dust proof ATC cnc processing center /AC servo /Vacuum table/Taiwan Syntec controller/5.5kw ATC spindles/3 axes dust proof
Features of machine:
1. Separate keyboard control: easy, convenience to learn, user can master the operation quickly, stronger independence
2. Advanced Taiwan numerical control system, Intelligent Technologies for Manufacturing: guard against the knock against due to the working area larger than table size. Intelligent processing speed control: can control the processing speed separately, promote efficiency, prolong cutter life, improve rate of finished products
3. Dust collection, Adsorption equipment: The dust collection system can take away the wood dust and flour, keep table clean and also maintain the machine; Adsorption system instead the fix up, save the time
4. Advanced file pretreatment function, help the user correct the error during the processing, can be compatible multi-software (for example Mastercam, Type3, UG, Artcam, Caxa, ect.).Advanced 3D curve forecasting method, fold line smoothly, ensure the speed and precision
5. Base on Windows flush bonding numerical control system. Soft and hard ware synchronous anti jamming design, ensure dependable operation. Have the memory of break point, power off function
6. Adopted steel seamless welded, hard and Non-Deforming
Scope of application
Furniture industry, solide furniture, solide door, Decorative Materials, cabinet door, computer table, mahjong table, panel-type furniture, office furniture, woody sound box, woody kitchen ware, ect.
Performance parameter
Travel |
X 2000mm |
Precision |
Processing ±0.02mm |
Structure |
Vacuum adsorb |
Z ball screw,X.Y pinion and rack | |
Machine consumable power |
2.8KW |
Speed |
Max idling speed 60000mm/min |
Spindle |
Spindle power 5.5 KW water cooling(made in China) |
Operation method |
Japan servo |
Work voltage |
AC380V/50Hz |
Commend code |
G code |
Operation system |
Taiwan Syntec |
vacuum pump |
5.5kw air pump |
Standard tool changer |
6 tools |
