Specifications
cnc engraving machine for plasterSKD-2030SA
1.3.0Kw water cooled spindle
2.Aluminum table with clamps
3.Step driver
cnc engraving machine for plaster
SKD-2030SA
Scope of application:
This machine is with multi-functions like engraving, cutting, milling, drilling, etc.Engraving and cutting, engrave on marble, granite, tombstone, jade and other stone material, also, glass, plastic, acrylic, metal and other non-metal material.
Features of the machine:
1.Adopts 3.0 kw watercooling spindle with very good performance , fit for long time producing in the processing line and easy maintain, fit for long time producing in the processing line and easy maintain. And the sprinkler can cool down the tool and work pieces effectively.
2.High performance transducer, high frequency electronic anti-jamming system.
3.The whole lathe is thickening steel structure,scientific welded, u pright and support plate, all using cast process that ensures the high stability.
4.The gantry structure, Y axis uses dual-motor dual-driven system, X, Y axis all use 25 mm TaiwanHIWIN dual-straight rail that make the machine driving smoothly with high-precision.
5. big torque stepper motors and high quality driver.
6.Use Ncstudio controll system,good compatibility, compatible type3 /artcam /Castmate /artcut/CAD /CAM and other design software. Can control the completion of multidimensional 3Dprocessing, and can do fast, smooth, 3d processing, carving and cutting.
7.Aluminium table with the water channel;
8.X.Y axes are especially produced by complete dust-prevent setup to ensure the rails and gears from damaged by the dust that produced while working and to-lengthen life of the parts.
9.the Z axis adopts TaiwanTBI original coarse pitch precise rubbing screw rod, Feed materials height is 200 mm;
10.Equipped with standard America industrial aviation plugs links, soft metal cable sheath .
11.The cable lines adopt imported high soft shielding machine cable reciprocating motion can reach 8 million times.
FC-1325SA Performance parameter:
Outer dimension |
2000*3000*1600mm |
X,Y axis travel |
1300*2500mm |
Z axis travel |
>200mm |
| Table size | 1340*2500mm |
| Max speed | 35m/min |
| Max feed-in height | 200mm |
| Command Language | G code u00 mmg plt |
| Software operating environment | Windows98/2000/Xp |
| Power(not include spindle) | 2Kw |
| Work voltage | 380V/50Hz |
| Spindle power | 3.0Kw |
| Spindle rotating speed | 6000-24000rmp |
| Work mode | Stepper(rack transmission) |
| Control system | NC Studio controller |
| Standard software | UCANCAMV9 |
