marble Three-dimensional CNC engraving machine SKD-0412AY-4

Specifications

I can speak Russian
stone CNC router
NC-studio
Low price





SKD-0412AY-4

stone CNC router



Feathers of the machine:



High Efficiency = One machine replace 36 workers.

High Performance = Four axes linkage control system. .

High Quality = Whole machine imported servo.

High Guarantee = Whole machine International Warranty Service.



1.Unique four-axis linkage design can automatically process complex polyhedron.

2.Domestic big power water-cooled spindle motor, high precision, long life, smooth operation, and good startup performance, big torch, and can give full play to the advantages of this machine's high speed and efficiency.

3.Overall thick steel bed, heavy square table support structure, science welding, non-deformed, high precision gantry milling holistic processing.

4.Standard industrial design, the whole machine's connect parts are all industrial cast aluminum to ensure the machine service life.

5.All axes use Taiwan TBI screw rod lead transmission, high precision and long life.

6.25mm imported linear guide, double rows and four lines of ball sliders, heavy loading capacity, smooth operation, high accuracy, and the high-strength high quality steel rails ensure the mechanical accuracy and wearability, rail service life is 10 times higher than the circular rail; imported high precision ball screw, high accuracy under the knife.

7.Adopt high-performance 4 axes control system, with excellent and stable quality, you can control the complete multi-level 4D processing, can be fast, smooth four-dimensional machining, engraving and cutting. And could operate after accident or next day processing so it is very convenient.

8.Good software compatibility, compatible with Type3/ Castmate/UCANCAM and other CAD/CAM designed software.

9.Equip with standard America industrial aviation plugs links, soft metal cable sheath, avoids the cable damage situation from the press & bump effectively.

10.cable adopts YC numerical control machine shielding line, can reciprocate twelve million times.



Performance parameter:







Performance parameter



Outer dimension	1800*680*1700mm
Work table area	680*1500mm
Working travel	200*800mm
Repositioning Accuracy	0.025mm
Spindle power	2.2KW(for chosen)
Work voltage	220V/50Hz
Running speed	18m/min
Spindle rotation speed	6000-24000rpm/min
Cutter diameter	3.175 4  6  12.7
Engraving dictate	G code ,uoo ,mmg ,plt
