Specifications
cnc mould router with super high Z axis /AC servo /HSD spindle /dust proof/Taiwan square rails/ Taiwan high accuracy ball screwcnc mould router with super high Z axis /AC servo /HSD spindle /dust proof/Taiwan square rails/ Taiwan high accuracy ball screw
[Feature]
1.The intellectualized 3D numerical control system, precise 3D controlling, realized the three axes linkage in real, make the tridimensional engraving
2.The machine tool adopt complete steel design, straight-quadrate rail, the world famous ball screw; adopt Japan Yaskawa servo system,PCI control card,high precision and high speed.
3.Adopted advanced Z axes photoelectricity tool setting equipment, reduce the operate difficulty, the tool setting precision can reach to 0.02MM.Can undertake MDP, convenient for X, Y direction exacted tool setting.
4.Spindle drive motor adopt high accurate ceramic bearing, prolong the service life
5.The move-working style of Particular platform ensures the accurate work pieces.
|
Performance Parameters
| |
Name |
FC-0610TW
|
|
Lathe Bed
|
Cast
|
|
Working area
|
1000mm x 600mm x400mm
|
|
X Y Z Guide Rail
|
Square Rail
|
|
X Y Z Transmission
|
Imported Ball Screw
|
Spindle motor |
Italy HSD 3.0KW air cooling
|
|
Inverter
|
Taiwan Delta
|
Control System |
NCstudio 63Acontrol system
|
|
Typeset Software
|
UCANCAM V9 |
Spindle speed |
6000-24000rpm
|
|
Reposition Accuracy
|
+_0.001
|
Motor |
Japan Yaskawa Stervo Motor
|
|
Driver
|
Japan Yaskawa/ Panasonic
|
|
Work-holding
|
Pneumatic clamping
|
|
Working speed
|
35m/min
|
Working voltage |
AC380v/50HZ |
|
Machine Weight
|
800kg |
Lubrication |
Manual lubrication system
|
Application |
wood,resin,acrylic,polypropylene,Plexiglass,plastic,soft metal,PVC, gypsum,rubber,etc. wood furniture,technic door and window, s chairs, alumium processing,arts and crafts,musical instrument,etc.
|
Warranty |
2 years (Spindle motor is one year. The blades, sensor, power cable are expendables, not include.)
|
Payment |
50% prepayment by T/T, Then the balance to be paid before delivery
|
Advantage |
Platform moving ,Mini mould working ,3 axis ball screw Transmission with high accuracy , Complete Function |
Sample :
Similar models :
