Specifications
We can Speak RussianCE
HIGH SPEED
High quality
low price
X,Y axis travel | 1300*2500mm |
Z axis travel | 200mm |
Transmission | Rack and pinion |
Max running speed | 30m/min |
Max engraving speed | 15m/min |
Max feed-in height | 220mm |
Command language | G code, M code |
Software operating environment | Windows98/2000/xp |
Work voltage | 380v/50Hz |
Spindle power | 4.5KW |
Spindle rotating speed | 6000-24000rpm/min |
Work mode | Stepping |
FC-1325SA Stone cnc router
Application:
Cnc router FC-1325SA special for stone is widely used in stone processing,mining industry,stone art work industry,etc.It can processing various stone,like marble,granite,sandstone,terrazzo(water stone),gypsum,etc.
Features of the machine: .
1. X,Y axis are specially protected by complete dust-prevent set up to ensure the rails and gears from damaged by the dust that produced while working and lengthen life of the parts.
2. The lathe welded use high-quality steel,by secondary quenching processing and upright, support plate, using aluminum cast process that ensures the high stability.
3. Equip large power stepping drive motor;X,Y,Z axises chosen Taiwan imported 25mm straight moving rails,smoothly running,without maintainion,long used.
4. Using high accurate pinion and rack transmission. The highest speed is 30m/min. It can clearly engrave the 1mm small word.
5. Z axis adopts Taiwan TBI original coarse pitch precise rubbing screw rod, high precision transmission
6. Spindle use 4.5kw water-cooling Spindle,6000-24000 rot/min,fit for long time producing in the stone working line.
7. water tank for water cycle.the water tank can collect the water which are used to cool down the stone during the engraving.
8. equipp with standard America industrial aviation plugs links, soft metal cable sheath, avoids the cable damage situation from the press & bump effectively.
9. cable adopts YC numerical control machine shielding line, can reciprocate eight million times.
10. Advanced industrial controlling system(NC studio control system) is compatible to many dictate formats that can operate after accident or next day processing so it is very convenient.
