Help CenterCnc Wood Door 3D Carving Machine
Related Products
Specifications
cnc engraving machine in wood routerFC-2030MS-4
1.2.2KW water cooled spindle
2.NC Studio controller
3.Step driver
cnc wood door 3D carving machine
FC-2030MS-4
Scope of application :
Our products have been widely applied in industrial boarding, mould manufacturing & processing, wooden products processing, building decorating & furnishing, stone, glass, copper, aluminum and advertising products processing, etc
Features of the machine:
1.Unique Z axis one plate with four spindles design,can process more batch jobs of small workpiece,improved of production greatly.
2.Domestic water-cooled spindle motor,high precision,long life,smooth operation,and good startup performance.
3.Overall thick steel bed,T-shape table support structure,science welding,non-deformed,high-precision gantry milling wholistic processing.
4.Patented special design of Z-axis industrial level dust preventation,so that protect the Z-axis rail and rack form dust and flakes.
5.Taiwan 20mm linear guide processing of up to 10 meters per minute.
6.Original Shanghai NC studio,with excellent and stable quality,good maintenance,you can control the complete multi-3D processing,can be fast,smooth three-dimensional machining,engraving and cutting.
7. Aluminum clamp working platform.
8.All machine cables are shielded under imported high soft shield machine cable,reciprocating motion more than 8 millio times,while American aviation industry standard plug,soft metal cable protection sleeve,easy to connect easily accessible,very low failure rate.
technology parameter:
| MODEL | FC-2030MS |
| Working travel | 2000*3000mm |
| Feeding height | 200mm |
| Resolution | 0.025mm |
| Spindle power | 2.2Kw*4V |
| Voltage | AC380V/50Hz |
| Running speed | 50m/min |
| Running speed of spindle | 6000-24000rpm/min |
| Hilt diameter | 3.175 4 6 12.7 |
| Engraving indicate | G(code).uoo.mmg.plt |
| Absorb power | NO |
| Work style | Servo/Step |
