12V 24AH Valve Regulated Lead Acid Storage Battery

12V 24AH Valve Regulated Lead Acid Storage Battery thumbnail-1
12V 24AH Valve Regulated Lead Acid Storage Battery photo-1
US$ 50 - 100 MOQ: 20 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
JIUHUA
Model Number:
12V24AH
Contact Supplier Request Quote Chat Now
Jiangsu Jiuhua Energy Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
ningbo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Jiangsu, China
Brand Name JIUHUA
Model Number 12V24AH
Usage Other, Storage
Voltage Other, 12v
Sealed Type Sealed
Maintenance Type Free
Size 175*165*125/165*125*175
Weight 7.2kg/7.6
Nominal Capacity 24ah

Specifications

1)lead acid battery with 24Ah
2)CE approved
3)Maintenance free battery.

Lead acid battery 12V24Ah:



Battery Structure:

12V 24AH valve regulated lead acid storage battery

1) Container/Cover: Made of UL94HB and UL 94-0ABS Plastic.

2) Negative Plates: Use the special PbCa alloy grids, optimize the recombination efficiency

and less gassing.

3) Separator: Import high quality AGM separator.

4) Positive plates: PbCa grids minimize corrosion and prolong life.

5) Terminal post: Copper material with maximum conductivity, enhance the high current rapidly.

6) Vent Valve: Allows the release of the excess gas automatically for safety.



Application:UPS, solar systems, control systems, power systems, wind energy systems,

telecommunication/communication systems and etc.



Installation Notice:

1) Lay the battery with up-down direction instead of put it inverted in any case.

2) Abnormal vibration or shock is not allowed.

3) Do insulate when installation.

4) Make the batteries ventilated and gapped.

5) Do not mixed up different brand and different manufacturing date batteries.

6) Separate the batteries from organic solvent.



ups battery, alarm system battery, lead acid battery

Internal Resistance: Fully charged  battery 25 °C------0.02 Ohm

Self Discharge: 3% of capacity declined per month at (25 °C)

ITEM NO. VOLTAGE(V) CAPACITY(AH) Dimension(mm) Weight(Kg) Packing
(pcs/ctn)
Length Width Height Total height
3-FM-1.3 6 1.3 97 24 52 57 0.30 60
3-FM-2.8 6 2.8 65 33 97 103 0.62 30
3-FM-3.2 6 3.2 124 33 60 65 0.65 20
3-FM-4 6 4 70 47 101 106 0.69 20
3-FM-5.5 6 5.5 67 67 96 103 0.82 20
3-FM-7 6 7 151 34 94 99 1.20 20
3-FM-9 6 9 98 56 118 118 1.55 10
3-FM-10 6 10 151 50 94 99 1.82 10
3-FM-12 6 12 151 51 94 99 1.90 10
3-FM-14 6 14 107 70 139 139 2.30 8
6-FM-0.8 12 0.8 96 25 62 62 0.35 20
6-FM-1.3 12 1.3 97 43 52 58 0.60 12
6-FM-2.2 12 2.2 177 35 61 66 0.98 10
6-FM-2.8 12 2.8 177 35 61 65 1.15 10
6-FM-3.2 12 3.2 134 67 60 64 1.30 10
6-FM-4 12 4 90 70 102 106 1.43 12
6-FM-5.5 12 5.5 151 50 94 99 1.80 10
6-FM-7 12 7 151 65 94 99 2.20 8/10
6-FM-9 12 9 151 65 94 99 2.65 8/10
6-FM-10 12 10 151 99 94 100 3.30 6
6-FM-12 12 12 151 99 94 100 3.85 6
6-FM-18 12 18 181 76 166 166 5.55 4
6-FM-24 12 24 175 166 125 125 6.50 2
6-FM-30 12 30 196 131 164 170 10.50 1
6-FM-40 12 40 196 165 170 170 13.30 1
6-FM-50 12 50 196 166 175 182 14.20 1
6-FM-55 12 55 230 138 208 213 17.50 1
6-FM-65 12 65 350 166 176 176 20.00 1
6-FM-70 12 70 260 167 209 227 21.90 1
6-FM-75 12 75 260 167 209 227 23.00 1
6-FM-85 12 85 350 167 173 180 25.00 1
6-FM-90 12 90 307 169 208 227 27.00 1
6-FM-100 12 100 329 172 215 220 29.00 1
6-FM-120 12 120 406 174 208 235 36.00 1
6-FM-150 12 150 483 170 241 241 46.00 1
6-FM-200 12 200 522 240 219 245 60.00 1
6-FM-250 12 250 520 268 220 249 72.00 1
3-FM-150 6 150 260 180 247 251 23.50 1



12V 24AH valve regulated lead acid storage battery12V 24AH valve regulated lead acid storage battery
