SMD 5050 Led Bar ,72 Pcs/m LED Bar,SMD Led Bar

SMD 5050 Led Bar ,72 Pcs/m LED Bar,SMD Led Bar thumbnail-1
SMD 5050 Led Bar ,72 Pcs/m LED Bar,SMD Led Bar photo-1
US$ 1 - 5 MOQ: 1 Piece
Key Specifications
Get Latest Price
LED Light Source:
smd 5050 led
Type:
LED Bar Lights
Input Voltage(V):
12V
Contact Supplier Request Quote Chat Now
Shenzhen Bright Technology Industrial Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
ShenZhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
LED Light Source smd 5050 led
Type LED Bar Lights
Input Voltage(V) 12V
Lamp Power 17.5W
Lamp Luminous Flux(lm) 1150-1200
Color Temperature(CCT) RGB,w
Working Temperature(℃) -40, 60
Working Lifetime(Hour) 50000
Lamp Body Material Aluminum
Certification CE, CE
Emitting Color Other, RGB, Pure White
Place of Origin Guangdong, China
Brand Name Bright 5050 led bar
Model Number BG-1705-5050-72 5050 led bar

Specifications

5050 led bar ,72 pcs/m LED bar,SMD led bar
Voltage:DC12V
Viewing angle : 120degrees;
life: 50,000 hours;
Color:White

SMD 5050 led bar,72 pcs/m LED bar,SMD led bar

Features:

1.Work voltage DC12V/24V

2.Standard length: 60led/pcs

3.PCB Width:10mm,

4. Available Color: White, Warm White, Red, Green, Blue, Yellow,RGB

5.SMD5050LEDs,60LEDs/meter.,72led per  meter

6.Beam Angle: 120 degree.

7.Light decay: Less than 5% after 1000 hours constant work.

8.Protect range: non-waterproof or waterproof IP65. Can be waterproof with nanomaterials coating.

9.Life Span: 50,000-80,000 hours

Specifications

Product NO.

LED TYPE

LED Qty.

Voltage

Current

Luminous Flux(lm)

Power

Color

PCB Material

IP Grade

View

 Angle

Size:mm

BG-1701-3528-60

SMD3528

60Pcs/m

12V DC

0.4 A

300-350

9.6 W

Single color

FR-4

No

120°

1000*8*4

BG-1702-3528-60

SMD3528

60Pcs/m

12V DC

0.8 A

290-335

9.6 W

Single color

FR-4

No

120°

1000*10*7

BG-1702A-3528-60

SMD3528

60Pcs/m

12V DC

0.8 A

275-325

9.6 W

Single color

FR-4

IP65

120°

1000*10*7

BG-1703-5050-60

SMD5050

60Pcs/m

12V DC

1.2 A

840-870

14.4W

Single color /RGB

FR-4

No

120°

1000*12*4

BG-1704-5050-60

SMD5050

60Pcs/m

12V DC

1.2 A

830-860

14.4W

Single color /RGB

FR-4

No

120°

1000*12*7

BG-1704A-5050-60

SMD5050

60Pcs/m

12V DC

1.2 A

810-840

14.4W

Single color /RGB

FR-4

IP65

120°

1000*12*7

BG-1705-5050-72

SMD5050

72Pcs/m

12V DC

1.45 A

970-980

17.5W

Single color /RGB

MCPCB

No

120°

1000*8*4

BG-1706-5050-72

SMD5050

72Pcs/m

12V DC

1.45 A

930-950

17.5W

Single color /RGB

MCPCB

No

120°

1000*12*20

BG-1706A-5050-72

SMD5050

72Pcs/m

12V DC

1.45 A

910-940

17.5W

Single color /RGB

MCPCB

IP65

120°

1000*12*20

APPLICATIONS

1.Jewelry counter lighting

2.Indoor decorative lighting and backlighting

3.Emergency hallway lighting

4.Auditorium walkway lighting

5.Indoor/outdoor illuminated signs and advertisements

6.Backlighting for larger size ad-signs

7.Elegant interior decoration

8.Nice accent lighting lamps

9.Landscape outlines, etc.

led light bar picture:

SMD 5050 led bar ,72 pcs/m LED bar,SMD led bar



SMD 5050 led bar ,72 pcs/m LED bar,SMD led bar



SMD 5050 led bar ,72 pcs/m LED bar,SMD led bar



SMD 5050 led bar ,72 pcs/m LED bar,SMD led bar



SMD 5050 led bar ,72 pcs/m LED bar,SMD led bar



SMD 5050 led bar ,72 pcs/m LED bar,SMD led bar

Picture of 5630 led strip:

SMD 5050 led bar ,72 pcs/m LED bar,SMD led bar



SMD 5050 led bar ,72 pcs/m LED bar,SMD led bar



SMD 5050 led bar ,72 pcs/m LED bar,SMD led bar



SMD 5050 led bar ,72 pcs/m LED bar,SMD led bar

Picture of 3528 led bar light:

SMD 5050 led bar ,72 pcs/m LED bar,SMD led bar



SMD 5050 led bar ,72 pcs/m LED bar,SMD led bar



SMD 5050 led bar ,72 pcs/m LED bar,SMD led bar



SMD 5050 led bar ,72 pcs/m LED bar,SMD led bar

matters needing attention:

1. Supply voltage of this product is 12v; never connect to other high voltage.

2. Never connect two wires directly in case of short circuit.

3.Lead wire should be connected correctly according to colors that connecting diagram offers.

express Delivery:

SMD 5050 led bar ,72 pcs/m LED bar,SMD led bar

Any questions, please don't hesitate to contact me, you're always welcome! (Sophie-Tuo)
