Digital medical oxygen regulator with flow meter:
Features:
Diaphragm regulator
1.The main part uses the goodness copper,using digit control machine tool to precision machining.
2.Lengthening air inlet valve lever , fit for the different capacity of oxygen cylinder.
3.Integrated Casting flowmeter
4.Long stroke Flow Switch
5.Spool of high wear-resistant stainless steel valve plug
6.Flow tube, wet cup of high-strength polycarbonate plastic body
7.High temperature high-pressure sterilized humidifier body, to meet European standards for B-level disinfection ;The maximum temperature of 121°C Pressure 0.142MPa
8.Polymer high-density filter, wet-based uniform.
Model:OX-8J
1.Gas Type :Medical oxygen
2.Inlet pressure: 2200psi
3.Outlet pressure :50psi
4.Pressure gauge size: 2inch/50mm
5.Pressure range:4000psi
6.Flow rate :1-15L/min
7.Inlet connections:
CGA540/0.908-14NGO-RH-INT
DIN477-9
UNI4406 O2(Optional)
CGA540/0.908-14NGO-RH-INT(Optional)
BS341-3 (Optional)
JIS W22-O-R (Optional)
CGA870/Pin-Indexed Yoke (Optional)
8.Outlet connections:DISS1240
9.Humidifier capacity:200ml
The package of Digital Medical oxygen regulator with flow meter:
Packaging: 10/pcs (box)
Package Size: 55x41.5X17.5cm
G/N.W:14.7/13.7kgs
