Low mistake for wholesales all over screen printing
USD $1 - $10
/ Set
1 Set(Min.Order)
- 100 Set / Sets per Month
- shenzhen ningbo Shanghai
- Credit Card PayPal
You May Like
Product Details
| Condition: | New | Place of Origin: | Guangdong, China | Brand Name: | scien-art |
| Model Number: | YKP70100 | Usage: | Card Printer, Cloths Printer, Label Printer, Paper Printer, Other, Card Printer, Cloths Printer, Label Printer, Paper Printer, transfer paper | Automatic Grade: | Semi-Automatic |
| Voltage: | 220V | Gross Power: | 2.3Kw | Dimensions(L*W*H): | 1600*1350*1280mm |
| Weight: | 455Kg | Certification: | CE/ISO | Warranty: | 1 year |
| After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Low mistake for wholesales all over screen printing :
video link : https://youtu.be/yisbZRDEpzs
all over screen printing :
| Model | YKP6090 | YKP-70100 | YKP90120 |
| Workbench Area (mm²) | 700*1000 | 800*1100 | 1000*1300 |
| Max Print Area (mm²) | 600*900 | 700*1000 | 900*1200 |
| Max Screen Size(mm) | 900*1200 | 1000*1300 | 1200*1500 |
| Min Screen Size(mm) | 450*550 | 550*650 | 650*700 |
| Frame Lift Height (mm) | 300 | 300 | 300 |
| Operation Air Pressure (Mpa) | 0.3-0.5 | 0.3-0.5 | 0.3-0.5 |
| Air-Consumption(0.6Mpa)(L/pcs) | 13 | 13 | 13 |
| Source Power (kw) | 2.3 | 2.3 | 2.3 |
| Rated Power (V/Hz) | 220/50 | 220/50 | 220/50 |
| Max Table Height(to floor) | 820 | 820mm | 820 |
| Printing Speed (pcs/h) | 500-1200 | 500-1200 | 500-1200 |
| Dimension (mm) L×W×H | 1500*1200*1250 | 1600×1350×1280 | 1800*1400*1300 |
| Weight (kg) | 410 | 480 | 550 |
Application Scope:
This machine is widely used in the ceramic decals, membrane switch, film, nameplate, paper packaging, gift box, craft glass, acrylic plate,transfer film,transfer paper. and other materials printing.
| |||
| Roll to roll screen printer | Automatic Screen Printer | Semi-Auto Screen Printer1 | Semi-Auto Screen Printer2 |
| |||
| LED UV Curing System | UV Dryer | Three Fourths Auto-Screen Printing Line1 | Three Fourths Auto-Screen Printing Line2 |
| in stock now, contact with me to know more informations, an inquiry and let me know by T/M will have discount !!!! |
