Clear Small Quartz Crucible

Beijing Zhong Cheng Quartz Glass Co., Ltd.
Clear Small Quartz Crucible thumbnail-1
Clear Small Quartz Crucible thumbnail-2
Clear Small Quartz Crucible thumbnail-3
Clear Small Quartz Crucible thumbnail-4
Clear Small Quartz Crucible thumbnail-5
Clear Small Quartz Crucible thumbnail-6
Clear Small Quartz Crucible photo-1
Clear Small Quartz Crucible photo-2
Clear Small Quartz Crucible photo-3
Clear Small Quartz Crucible photo-4
Clear Small Quartz Crucible photo-5
Clear Small Quartz Crucible photo-6
US$ 1 - 1,000 MOQ: 1 Piece
Key Specifications
Get Latest Price
Materials:
Quartz
Applications:
Laboratory Heating Equipments
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Materials Quartz
Applications Laboratory Heating Equipments

ZCQ supply our clients with various Laboratory Quartzware:



Clear Quartz Crucible



 Clear Small Quartz Crucible







Φ m/m

H m/m

R m/m

δm/m

60±0.7

45±1.5

35±0.35

2.0±0.2

70±0.7

50±1.5

35±0.35

2.0±0.2

80±0.7

60±2

40±0.35

2.5±0.3

90±0.8

70±2

45±0.4

2.5±0.3

100±0.8

80±2

50±0.4

2.5±0.3

110±0.9

80±2

55±0

2.5±0.3

125±0.9

80±2

62.5±0.05

2.5-3

125-0.5

80±0.5

62.5±0.05

2.5-3



 ZCQ Quartz Labware

Quartz Beaker (Low & Tall Form)                  Cell, Cylinder

Test Tube (With or With No Lid)                    Flange Pipe (Flange Ring)

Crucible (Low & Tall Form)                            Evaporating Dish

Carrier/ Boat (Flat or Round Bottom)              Distilling Flask

Ball Joint,Taper & Socket Joint                       Kjeldahl Flask

Anti-Heat Jacket                                            Volumetric Flask

Round Dish                                                     Boiling Flask

Cuvette                                                          Spiratron (Tubes in Coil)  Stopcocks



 Typical Characteristics of Quartz:

  Very Low Coefficient of Thermal Expansion
   Resistance to High Temperature
   High Chemical Purity
   High Corrosion Resistance
   Extensive Optical Transmission from Ultra-Violet to Infra-Red
   Excellent Electrical Insulation Qualities



Techincal Information of Transparent Quartz Materials:

Typical Mechanical Property of Fused Quartz



Mechanical Property

Reference Value

Mechanical Property

Reference Value

Density

2.203g/cm3

Refractive Index

1.45845

Compressive Strength

>1100Mpa

Coefficient of thermal expansion

5.5×10-7cm/cm.°C

Bending Strength

67Mpa

Hot work temperature

1750~2050°C

Tensile Strength

48.3Mpa

The temperature for a short time

1300°C

Poisson's Ratio

0.14~0.17

The temperature for a long time

1100°C

Elastic Modulus

71700Mpa

Resistivity

7×107Ω.cm

Shearing Modulus

31000Mpa

Dielectric Strength

250~400Kv/cm

Moths Hardness

5.3~6.5(Moths Scale)

Dielectric Constant

3.7~3.9

Deformation Point

1280°C

Dielectric absorption coefficient

<4×104

Specific Heat(20~350°C)

670J/kg °C

Dielectric loss coefficient

<1×104

Thermal Conductivity(20°C)

1.4W/m °C







ZCQ offers:

High Purity Material  and High Precision Manufacturing
Customer design and great Catagory
Competitive Price and  No minimum order restriction
Fast Delivery and complete after-sale services

Please call us and send us email for an inquiry .





 Clear Small Quartz Crucible





Packaging & Shipping

package: protection paper, green air bag,  air film, carton ,

                  safe and ecnomic even for freight collect as well.

Shipping methods and charges:

China post(15-25days)

Epacket to USA (10-15days)

EMS(7-10days)

Fedex(5-7days)

DHL(5-7days)

Actual shipping charge will be calculated upon product weight.

Clear Small Quartz Crucible



Our Services

1.Based in Beijing, heart of China, ZCQ is a technology and quality oriented manufaturer with 20 years history.

2.With senior engineer supervise, we are glad  to advise customers on pressure, temperature etc application and engineering questions.

3.ZCQ  accepts second production in case some products don’t meet requirements.

4.1 hour from international meeting center of Beijing, ZCQ invites guests to visit our company after long day meeting and get relaxed in nature. Our company is also sitted in arms of mountains and river.

Clear Small Quartz Crucible
