new solar products 2013 split pressurized solar collector
- 200 Piece / Pieces per Month
- Qingdao
- High Efficiency Full Black Solar Cells Panel factory Prices For Sale PV Module 400W Solar Panels
- 500w Solar Panel,Pv Module 500w,Solar Panels High Efficiency Full Black500w Solar Panel,Pv Module 500w,Solar Panels High Efficiency Full Black
- 500W High Power Monocrystalline 72 Solar Cells Solar Module Photovoltaic Panel
- high efficiency 550w 600w Customized solar panels half cell photovoltaic module manufacturer
- Shunyang warehouse in stock 540W 550W 560W photovoltaic solar panels made in China
- Shunyang solar 640W Hot selling photovoltaic solar panels with good quality and wholesale price
Product Details
Place of Origin: | Shandong, China | Brand Name: | Guangpu new solar products 2013 | Model Number: | new solar products 2013 heat pipe solar collector |
Type: | Pressurized | Application: | Water Heater | Pipe Material: | Glass |
Product Description
Specifications
new solar products 2013 All glass heat pipe solar collector with high efficiency and low heat loss coefficientWhy choose us:
A: 18 years experience in solar vacuum tube
B: First quality, Promptly delivery, Customer first
C: Competitive price & Free sample for test
Guangpu ,established in 1995,is a leading professional manufacturer of solar thermal products ,especially in sollar vacuum tube. We are one of the drafters of the national standard of “All-glass heat pipe- evacuated solar collector tubes" for the National Standardization Committee. In 18-year development,we have possessed advanced technology and superior equipments for quality, schedule and cost control. We have annual production capacity over 10 million of various high-quality all-glass evacuated solar collector tubes.We have been continuously supplying solar products with best quality to well-known solar thermal companies both in China and other counties across the world. With 18 years experience and professional knowledge ,we are glad to help your team succeed through our cooperation.
All glass heat pipe solar vacuum tube
Heat pipe Specification | |
Structure | Two concentric borosilicate glass tubes |
Material | Borosilicate glass 3.3 |
Outer tube diameter | Φ47±0.7mm &=1.6mm |
Φ58±0.7mm &=1.6mm | |
Inner tube diameter | Φ37±0.7mm &=1.6mm |
Φ47±0.7mm &=1.6mm | |
Length | 47mm-1500mm |
58mm-1800mm | |
Coating | SS-ALNx/Cu |
Solar absorption efficiency | 0.90~0.95AM1.5 |
Launch ratio | 0.04~0.06(80oC±5oC) |
Vacuum degree | P≤5.0×10-3 (Pa) |
Max stagnation temperature | 260~300 |
Vacuum degree of inner tube | P≤1.0×10¯³ (Pa) |
Average heat loss coefficient | ULT= 0.4~0.6w/(m2.oC) |
Length of Condenser | &=125mm±5mm(Φ47-1500mm ) |
&=145mm±5mm(Φ58-1800mm) | |
Resistance performance | Hail diameter≤ 25mm |
Heat pipe solar collector specification | |
Outer Tank | white pearlescent platethickness: δ=0.32mm |
Inner Tank | aluminum alloy; preservative treatment =2mm |
Insulation | polyurethane foaming; thickness: δ=30mm |
Dimension | 1840*2180*170mm |
Aperature area | 1.95m2 |
Distance between each two tubes | 80mm |
Weight | 82kg |
Capacity | 7.9L |
NOS of evacuated tubes | 20 pieces |
Max. /Working Pressure | 1/0.6 Mpa |
Advantages
(1).Superior thermal conductivityIt can transfer much more heat energy even than silver, copper or aluminum which has very high heat conductivity.
(2).Superior isothermal stability: There is little pressure drop as well as temperature drop in the inner tube.
(3).The density of heat flow in the inner tube can be changed by modifying the heating surface of the condenser or the evaporation part.
(4). It can be used in both pressurized and unpressurized systems.
(5). Heat energy of the hot water in the tank will not lose through the condenser when the tube stops absorbing solar energy as there is a vacuum in the inner tube.
(6). The tube is anti-freezing for there is no water in the tube.
