cnc router for stone carving 1325 cnc carving marble granite stone carving cnc machine for sale
- 100 Set / Sets per Month
- Qingdao port
- Credit Card
- Granite Marble CNC Milling and Cutting Bridge Saw Machine Infrared Quartz 5 Axis Granite Tile Back Splash Machine Cnc
- Bridge saw type cnc stone cutting machine for marble granite quartz kitchen countertop
- automatic stone cutting machine/cnc granite cutting machinery Bridge Saw for stone countertop
- 2024 new CNC four-axis bridge stone cutting machine for Artificial granite marble slabs
- 5 axis 45 degree chamfering granite quartz bridge saw stone carving cutting machine
- Integrated Mobile Bridge Saw Adopts Microcomputer Control Used Marble Simple Stone Granite Infrared 5 Axis Cnc Cutting Machine
Product Details
Condition: | New | Type: | Stone Engraving Machine | Use: | Granite |
Place of Origin: | Shanghai, China | Brand Name: | QL | Model Number: | QL-1325 |
Voltage: | AC380V,50HZ | Weight: | 1200kg | Certification: | ce |
Warranty: | one year, one year |
Product Description
cnc router for stone carving 1325 cnc carving marble granite stone carving cnc machine for sale
the factors you are interested in:
1.we are one factory, machine warranty time is one year,welcome to visit our factory.
2.we have all kinds of machines: wood cnc router-stone cnc router-metal cnc router-advertising cnc router.laser machine and plasma cutting machine.
3.we are based on the strong sales network and stable quality, best selling products are all have wide stock.
4.we have the technical sales managers who can speak fluent English,answer you questions in 24 hours.
Technical specification:
Model | QL-1325 | Optional
|
Working area (X*Y*Z,mm) | 1300*2500*300mm | customization is available
|
Machine structure | Thick-walled square tube structure lathe bed and T-slot table of sectional materials |
|
Working holding | by clamps |
|
Overall dimension | 2700*1850*1700/2950*2100*1700/3050*2800*1700 |
|
Precision(mm) | 0.07
|
|
Position accuracy(mm) | 0.02
|
|
Repeatability(mm) | 0.02
|
|
Lding speed (mm/min) | 9,000
|
|
Working speed(mm/min) | 5,000 |
|
Spindle | 5.5kw,water-coolin(0-24000rpm) | air-cooling(0-18000rpm),any KW
|
Available tools(mm) | φ3.175~φ12.7
|
|
Drive system | Stepper motor | Servo motor
|
Working voltage | AC380V±30V,50HZ |
|
Command code | G Code(*.nc,*.mmg,*.u00,etc),*.eng
|
|
Control system | NcStudio | DSP or depend on your needs |
Compatible software | Window98/XP/7 G code |
|
Product overview:
Heavy duty stone CNC Router is at the service of customers who need to do engraving on stone.overall structure is the most solid for large bearing capacity.with tool cooling system and water-and -dust proof on three axes,it is suitable for many kinds of stone carving.
Products features:
1.lethe bed uses thick-walled square tube structure with good rigidity and strength that can load heavy materials weighting up to one ton.
2.High-power spindle provides large cutting intensity and high efficiency.
3.Tool cooling system ensures effectively processing effect and improves tool life.
4.Water/dust proff on three axes makes transmission system clean and rust-proff for good accuracy and longer life.
5.Automatic oiling system can lubricate rails to ensure working accuracy,effectively extending machine’s lifespan.
Application:
Most perfect for engraving on common stone like marble,bluestone and even on hard stone like granite,it is also capable for engraving on glass of thickness more than 5mm.
Suitable to not only stone engraving for tombstone ,tile or other related industries,but also can do jobs with skill and ease on common material in woodworking ,advertising and metal industry with a wide range and application and high practicality.
machine and key parts for your reference:
samples made by stone cutting router machine:
company photos for your check:
certificate:
looking for agents all over the world
