cnc wood engraving machine/wood stair cnc router machine
specification
1.QILI-1530 wood carving cnc router
2. 4.5kw wood cnc machine structure heavy cheap cnc router
3.overall dimensions:2300*3650*1350
4.stepper motors
5.by vacuum table cnc router
Product overview:
1.It is common type woodworking machine with high performance configuration.
2.The request on several parts are even higher than of stone router,so that the engraving and cutting work on hard or thick materials could be done easily.
3.Most working need on various materials can be met as a typical of multi-functional machines.
Machine features :
1 Square Tube lathe bed with more solid structure and strong stability because of low center of gravity.
2 DSP hand-held control system.with U disk available and no need of computer,provides high independence
and great convenience for operation.
3.Breakpoint restoring function enable the machine conue to work affer sudden stop, such as accident, tool breaking.
Technical specifications:
Model |
QL-1530 |
Working area (X*Y*Z,mm) |
1500*3000*200 |
Machine structure |
square tube lathe bed,vacuum table |
Working holding |
By clamps |
Overall dimension |
3650*2300*1650 |
Precision(mm) |
0.07 |
Position accuracy(mm) |
0.02 |
Repeatability(mm) |
0.02 |
Lding speed (mm/min) |
25,000 |
Working speed(mm/min) |
15,000 |
Spindle |
4.5kw,water-coolin(0-24000rpm) |
Available tools(mm) |
φ3.175~φ12.7 |
Drive system |
Stepper motors |
Working voltage |
AC380V±30V,50HZ |
Command code |
G Code(*.nc,*.mmg,*.u00,etc),*.eng |
Control system |
DSP Hand-held |
Compatible software |
Window98/XP/7 G code |
All the parts of machine can do some changes to meet your requirements
such as the motor (step motor or servo motor ), spindle (air cooled or water-cooled ),inverter(DELTA or FULING) and the table of the machine also can be customized and so on .
The more you need to change some parts
Applicable Fields:
1.Furniture Decoration Industry:A large area flat plate engraving,wood, panel furniture carving,wood art
murals,wood cabinet doors carving.
2.Wood Products Processing:Sewing machine table, electrical counter table, sports equipment.
3.Artwork:Photo Frame, jewelry box.
4.Musical Instrument Industry:Instrument three-dimensional surface engraving,shape cutting.
Smples show
Our work environment as well as some inventory
Packaged good goods will be shipped
attending fair photo:
Our company
1.Jinan Hongye CNC Machine Co.,Ltd is a professional manufactuer of CNC Routers which was built in 2002.
Since our factory was founded, we are devoted in CAD/CAM carving technology and the research and
development of CNC numerical control technology. We made a considerable progress in the design theory of
precision engraving machine and the processing technology aspect. We successfully realized the automation control
technology, which was transformed to industrial production.
2.For 12 year's hardworking and perfect management, Hongye CNC rely the competitive price ,excellent quality
and good service won the good reputation of domestic and overseas clients.
3.With fine fitting parts and advanced technique, our products expand stably, in the fields of advertisement, carpentry,
and metal molds.
2.4.With superior performance-to-price ratio, high quality, and perfect post-sales service, the market share
of our products expands unceasingly. We will unceasingly develop and innovation with our factory.
We wait for you here
customers
A lot of golden members all over the world, you can really trust us!
FAQ
1)This is the first time I use this kind of machine, is it easy operate?
There are english manual or guide video that show how to use machine.
If there is still have any question, we can talk from phone or skype.
2)Can you recommend a CNC ROUTER MACHINE to me,thanks?
Yes, In order to give you a suitable router machine, pls tell me the max working area, materials for processing and
the thickness for materials processing engraving or cutting. Then perfect suitable cnc router will be recommended
3) If machine have any problem after I ordered it, how could I do?
Free parts send to you in machine warranty period if machine have any problemFree after-sales service life for machine,
please feel free contact us if your machine have any problem. we will give you 24hours service from phone and skype.
4) MOQ ?
Our MOQ is 1 set machine. We could send machine to your country port directly, please tell us your port name. There will
be best shipping freight and machine price send to you
5)Payment terms
a. 30% by T/T in advance,70% bY T/T before shiping
b. L/C is acceptiable ,if the amount is big,please issue the draft for our confirmation at first.
6)Delivery terms
We will arrange the delivery as the terms we both agreed with after the confirmation by the buyer
Guarantee&Aftersales Service:
1.Guarantee for one year
2.24-hour technical support by email or phone
3.User-friendly English manual and video CD for machine using and maintaining
4 .Providing free operation training service in our factory.
Look forward to your enquiry on our woodworking router machine .all kinds machines you can choose.
