hobby wood cnc router machine QL-1218 with high precision
Specifications router
A lot of golden members all over the world, you can really trust us!
1.customization is available
2.1200mm*1800mm*120mm working size
3.can be 3d engaving
4.cheap price for making money
5.good quality
6.four independent heads
Product Overview
Advertising series is designed for engraving and cutting most advertising material with various application and reasonable price. High precision engraving meets the diverse needs in advertising industry.
Product Features
1.Square linear quide tracks provide large loading capacity.
2.Doubel-net ball screws from German offer high working accuracy.
3.Restoring function enable the machine continue to work after sudden stop,such as accident,tool breaking.
4.Sample made out is not only delicate without serrature, the botto is smooth and in high edge sharpness.
5.Square guides on axis Y is optional for high accuracy request in lrage size material.
Technical Specification
| Model | QL-1218 | Optional |
| Working Area(X*Y*Z,mm) | 1200*1800*120 | Customization is available |
| Machine Structure | Steel structure lathe bed, T-slot table of sectional material | vacuum table |
| Work Holding | By Clamps | |
| Overall Dimensions(mm) | 1650*2300*1250 | |
| Precision(mm) | 0.07 | |
| Positioning accuracy(mm) | 0.02 | |
| Repeatability(mm) | 0.02 | |
| Idling Speed(mm/min) | 6.000 | |
| Working Speed(mm/min) | 4.500 | |
| Spindle | 1.5 water-cooling(0-24000rpm) | specified power, ari-cooling(0-18000rpm),multi-head |
| Drive System | stepper motors | Servo motors |
| Working Voltage | AC220V+30V,50HZ | |
| Command Code | G Code(*.nc.*.mmg.*.u00,ect.),*.eng | |
| Control System | Ncstudio system | DSP Hand-held |
| Compatible Software | Compatible with any software generating G code file in Window 98/XP/7 | |
| Other options | Dust collection,tool cooling system with sink,rotary axis |
Scope of application
Advertising sign making,plastic molding, characters cutting,LED light slot, light box molding etc.
For most advertising material working,such as acrylic,plastic board, double-color plates,MDF,PVC to named a few,And also no problems with soft metal like copper,aluminum and simple woodworking in similar material with MDF.
Details of advertising cnc router
Samples show
Factory&Packing
1.Jinan Hongye CNC Machine Co.,Ltd is a professional manufactuer of CNC Routers which was built in 2002.
Since our factory was founded, we are devoted in CAD/CAM carving technology and the research and
development of CNC numerical control technology. We made a considerable progress in the design theory of
precision engraving machine and the processing technology aspect. We successfully realized the automation control technology,which was transformed to industrial production.
2.For 12 year's hardworking and perfect management, Hongye CNC rely the competitive price ,excellent quality and good service won the good reputation of domestic and overseas clients.
3.With fine fitting parts and advanced technique, our products expand stably, in the fields of advertisement,
carpentry, and metal molds.
4.With superior performance-to-price ratio, high quality, and perfect post-sales service, the market share
of our products expands unceasingly. We will unceasingly develop and innovation with our factory.
Exhibition&Clients
our clients are from all over the world,welcome you join us!
Our team
Certificate
Sales Network
Guarantee&Aftersales Service
1.Guarantee for one year
2.24-hour technical support by email or phone
3.User-friendly English manual and video CD for machine using and maintaining
4 .Providing free operation training service in our factory.
Our Advantages
1. At the same quality grade, our products' price is better.
2. At the same products' price level, our service is better
3.5-9 days delivery,One year’s warranty
4.Response within 24 hours
5.OEM and ODM service provided
6.Standard Package box
7.CE, FDA, BV certificates
8.English, French, Spanish,Russian, Arabic etc languages support.
1) This is the first time I use this kind of machine, is it easy operate?
There are english manual or guide video that show how to use machine.
If there is still have any question, we can talk from phone or skype.
2)Can you recommend a CNC ROUTER MACHINE to me,thanks?
Yes, In order to give you a suitable router machine, pls tell me the max working area, materials for processing and the thickness for materials processing engraving or cutting. Then perfect suitable cnc router will be recommended
3) If machine have any problem after I ordered it, how could I do?
Free parts send to you in machine warranty period if machine have any problem.
Free after-sales service life for machine, please feel free contact us if your machine have any problem. we will give you 24hours service from phone and skype.
4) MOQ ?
Our MOQ is 1 set machine. We could send machine to your country port directly, please tell us your port name. There will be best shipping freight and machine price send to you
5)Payment terms
a. 30% by T/T in advance,70% bY T/T before shiping
b. L/C is acceptiable ,if the amount is big,please issue the draft for our confirmation at first.
6)Delivery terms
We will arrange the delivery as the terms we both agreed with after the confirmation by the buyer
If you want to know more details about our machines,please contact me at any time,welcome to visit our factory.
If you want to buy high quality products,just join us!!!
Contact: Tell:008653188611918 Skype:Nancy Liang
